Page #415 background imageLoading...
Page #415 background image
UHF Band 2 Circuit Board/Schematic Diagrams and Parts List (PCB 8415235H01, 8415235H05) 9-265
C445 2113944A40 CAP CER CHP 100.0PF 50V
5%
C447 2113945B04 CAP,FXD,.022UF,+10%,-10%,
25V-DC,04
C448 2113946B04 CAP CER CHP 0.10UF 10V
10%
C449 2113944A40 CAP CER CHP 100.0PF 50V
5%
C450 NOT PLACED
C451 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C452 2113743B29 CAP CHIP 1.00 UF 10% 16V
C453 2113944A40 CAP CER CHP 100.0PF 50V
5%
C456 2113944A40 CAP CER CHP 100.0PF 50V
5%
C458 2113944A40 CAP CER CHP 100.0PF 50V
5%
C459 2113944A40 CAP CER CHP 100.0PF 50V
5%
C463 2113944A40 CAP CER CHP 100.0PF 50V
5%
C466 2113944A40 CAP CER CHP 100.0PF 50V
5%
C467 2113946B04 CAP CER CHP 0.10UF 10V
10%
C471 2113944A40 CAP CER CHP 100.0PF 50V
5%
C472 2113945A05 CAP CER CHP 470PF 50V
10%
C473 2113945A05 CAP CER CHP 470PF 50V
10%
C475 2113743H14 CAP CHIP 10.0 UF 16V +80-
20%
C476 2113946R01 CAP CER CHP 10.0UF 10V
C479 2113946B04 CAP CER CHP 0.10UF 10V
10%
C480 2113946R01 CAP CER CHP 10.0UF 10V
C481 2113946B04 CAP CER CHP 0.10UF 10V
10%
C482 2113946B04 CAP CER CHP 0.10UF 10V
10%
C490 2113944A40 CAP CER CHP 100.0PF 50V
5%
C491 2113944A40 CAP CER CHP 100.0PF 50V
5%
C492 2113944A40 CAP CER CHP 100.0PF 50V
5%
C493 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref
Motorola
Part No.
Description
C494 2113944A40 CAP CER CHP 100.0PF 50V
5%
C495 2113944A40 CAP CER CHP 100.0PF 50V
5%
C496 2113944A40 CAP CER CHP 100.0PF 50V
5%
C497 2113944A40 CAP CER CHP 100.0PF 50V
5%
C498 NOT PLACED
C499 2113946B04 CAP CER CHP 0.10UF 10V
10%
C502 2313960A55 CAP TANT 0.47 UF 10% 25V
3216-18
C503 2113944A84 CAP,FXD,43PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C505 2113944A40 CAP CER CHP 100.0PF 50V
5%
C511 2113944A40 CAP CER CHP 100.0PF 50V
5%
C512 2113944A40 CAP CER CHP 100.0PF 50V
5%
C513 2113944A40 CAP CER CHP 100.0PF 50V
5%
C514 2113944A40 CAP CER CHP 100.0PF 50V
5%
C520 2113945B02 CAP CER CHP 10,000PF 25V
10%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C524 2113944A40 CAP CER CHP 100.0PF 50V
5%
C525 2113944A40 CAP CER CHP 100.0PF 50V
5%
C526 2113944A40 CAP CER CHP 100.0PF 50V
5%
C527 2113944A40 CAP CER CHP 100.0PF 50V
5%
C528 2113944A40 CAP CER CHP 100.0PF 50V
5%
C529 2113944A40 CAP CER CHP 100.0PF 50V
5%
C597 2113944A84 CAP,FXD,43PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C598 2113944A15 CAP CER CHP 3.9PF 50V +/-
0.25PF
Circuit
Ref
Motorola
Part No.
Description
C599 2113944A17 CAP CER CHP 4.7PF 50V +/-
0.25PF
C600 2113944A81 CAP,FXD,24PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C601 2113944A40 CAP CER CHP 100.0PF 50V
5%
C602 2113944A17 CAP CER CHP 4.7PF 50V +/-
0.25PF
C603 2113944C81 CAP,FXD,24PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C604 2113944C81 CAP,FXD,24PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C610 2113944A40 CAP CER CHP 100.0PF 50V
5%
C611 2113944A40 CAP CER CHP 100.0PF 50V
5%
C612 2113944A40 CAP CER CHP 100.0PF 50V
5%
C613 2113944A40 CAP CER CHP 100.0PF 50V
5%
C615 2113944A40 CAP CER CHP 100.0PF 50V
5%
C616 2113944A40 CAP CER CHP 100.0PF 50V
5%
C618 2113944A40 CAP CER CHP 100.0PF 50V
5%
C619 2113944A40 CAP CER CHP 100.0PF 50V
5%
C620 2113944A40 CAP CER CHP 100.0PF 50V
5%
C621 2113944A40 CAP CER CHP 100.0PF 50V
5%
C622 2113944A40 CAP CER CHP 100.0PF 50V
5%
CR101 4880973Z02 PIN DIODE
CR102 4815257H01 SURFACE MOUNT PIN
DIODES
CR103 4815257H01 SURFACE MOUNT PIN
DIODES
CR105 5115022H01 IC,TEMP
SENS,LM50C,SM,SOT-23
CR160 NOT PLACED
CR201 4815011H01 DIODE,SWG,300MA,80V
CR203 4815072H01 DIODE,VCTR,1SV232,30V
CR241 4885094Y01 DIODE VARACTOR ISV228
W18
CR242 4885055Y01 DIODE VARACTOR PB-FREE
CR243 4885055Y01 DIODE VARACTOR PB-FREE
Circuit
Ref
Motorola
Part No.
Description
CR251 4815322H01 VHF VARIABLE
CAPACITANCE DIODE
CR301 4885055Y01 DIODE VARACTOR PB-FREE
CR302 4885055Y01 DIODE VARACTOR PB-FREE
CR303 4815048H01 DIODE,SHTK,MMBD353LT1,
SM,7V
CR304 4885055Y01 DIODE VARACTOR PB-FREE
CR305 4885055Y01 DIODE VARACTOR PB-FREE
CR306 4802245J42 RING QUAD DIODE SOT-143
PKG
CR311 4813974A19 DIODE SCHOTTKY
BARRIER SERIES
CR312 4815047H01 DIODE,SWG,DAN235EFTL,3
5V
CR313 4815047H01 DIODE,SWG,DAN235EFTL,3
5V
CR411 4815067H01 DIODE ARRAY,SWG,
RB731UFT108,SMD,1M
CR412 4815067H01 DIODE ARRAY,SWG,
RB731UFT108,SMD,1M
CR413 4815067H01 DIODE ARRAY,SWG
,RB731UFT108,SMD,1M
CR440 4813978C02 PB FREE, NOT
COMPLETELY ENRICHED
CR501 4815155H01 RECTIFIER
CR503 4805729G49 DIODE RED/YEL
D601 4880479U01 LED
D602 4880479U01 LED
D603 4880479U01 LED
D604 4880479U01 LED
D605 4880479U01 LED
D606 4880479U01 LED
E101 2415954H01 INDUCTOR BEAD CHIP
E102 7686949J14 FLTR,FERRITE
BEAD,2A,SM,0805
E105 7686949J14 FLTR,FERRITE BEAD,2A,
SM, 0805,CHIP,220OHM
E400 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E401 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E402 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E403 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E404 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E405 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E406 2480640Z01 SURFACE MOUNT FERRITE
BEAD
Circuit
Ref
Motorola
Part No.
Description
