Motorola HT Series User Manual

UHF Section 9-281
C442 2113743E20 10uF
C443 2113928N01 0.1uF
C444 2113743N50 100pF
C445 2113743N50 100pF
C447 2113743M08 0.022uF
C448 2113928N01 0.1uF
C449 2113743N50 100pF
C451 2113743M08 0.022uF
C452 2113743G26 4.7uF
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF
C471 2113743N50 100pF
C472 2113743L09 470pF
C473 2113743L09 470pF
C475 2113743H14 10.0uF
C476 2113928D08 10.0uF
C479 2113928N01 0.1uF
C480 2113928D08 10.0uF
C481 2113928N01 0.1uF
C482 2113928N01
0662057M01
0.1uF, 10%
0 (SUB on Models LS
+
Only)
C490 2113743N50 100pF
C491 2113743N50 100pF
C492 2113743N50 100pF
C493 2113743N50 100pF
C494 2113743N50 100pF
C495 2113743N50 100pF
C496 2113743N50 100pF
C497 2113743N50 100pF
C502 2311049A05 0.47pF
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 0.01uF
C521 2113743L41 0.01uF
C522 2113743L41 0.01uF
C523 2113743L41 0.01uF
CR101 4880973Z02 Pin Diode
CR102 4802245J41 Pin Diodes
CR105 5185963A15 Temperature Sense
CR201 4802233J09 Diode Triple
CR203 4862824C03 Varac to r
CR241 4805649Q13 Dual Varactor
CR242 4862824C01 Varac to r
CR243 4862824C01 Varactor
CR251 4802245J22 Varac to r
CR301 4862824C01 Varactor
CR302 4862824C01 Varac to r
Circuit
Ref
Motorola Part
No.
Description
CR303 4880154K03 Dual Common Anode-cathode
CR304 4862824C01 Varac to r
CR305 4862824C01 Varactor
CR306 4802245J42 Ring Quad Diode
CR308 4802245J41 Pin Diodes
CR310 4862824C01 Varac to r
CR411 4802245J47 Diode Schottky
CR412 4802245J47 Diode Schottky
CR413 4802245J47 Diode Schottky
CR440 4813833C02 Dual Diode Common Cathode
CR501 4880107R01 Rectifier
CR503 4805729G49 Led Red/yellow
E101 2484657R01 Ferrite Bead
E400 2480640Z01 Ferrite Bead
E401 2480640Z01 Ferrite Bead
E402 2480640Z01 Ferrite Bead
E403 2480640Z01 Ferrite Bead
E404 2480640Z01 Ferrite Bead
E405 2480640Z01 Ferrite Bead
E406 2480640Z01 Ferrite Bead
E407 2480640Z01 Ferrite Bead
E408 2480640Z01 Ferrite Bead
E409 2480640Z01 Ferrite Bead
F501 6580542Z01 Fuse 3A
FL201 4802245J49 16.8 MHz Xtal Clip (not field
serviceable)
FL301 4802245J43 Crystal Filter 45.1 MHz
FL401 4870368G02 Clock Oscillator Crystal
(not used in HT750 or PRO5150)
H101 2680499Z01 Heat Spreader
J101 0180117S05 RF Jack Assembly
J102 0280519Z02 Nut, Antenna
J400 0905505Y04 40 Pin Connector
J403 0905505Y02 20 Pin Connector
L101 2479990B02 19.61nH
L102 2479990B02 19.61nH
L104 2479990B02 19.61nH
L105 2462587N22 390nH
L106 2479990A02 7.66nH
L107 2479990G01 33.47nH
L108 2479990A01 4.22nH
L109 2479990B01 11.03nH
L112 2462587N45 22nH
L113 2413926H09 5.6nH
L114 2462587N22 390nH
L115 2462587N22 390nH
L116 2479990A03 9.75nH
L160 2413926H14 15.0nH
L201 2462587Q20 2.2uH
L202 2462587Q20 2.2uH
L203 2462587Q20 2.2uH
L232 2462587P25 12uH
L241 2462587V41 390nH
L242 2462587V38 220nH
L243 2460593C01 Teflon Resonator
L251 2462587V28 33nH
Circuit
Ref
Motorola Part
No.
Description
L253 2460593C02 Teflon Resonator
L261 2462587V29 39nH
L271 2462587V32 68nH
L273 2462587V28 33nH
L281 2462587V41 390nH
L282 2462587V41 390nH
L301 2479990C01 13.9nH
L302 2479990C01 13.9nH
L303 2462587V26 22nH
L304 2462587V37 180nH
L305 2462587V26 22nH
L306 2479990C01 13.9nH
L307 2479990C01 13.9nH
L309 2479990C02 16.28nH
L310 2462587V36 150nH
L311 2462587N65 750nH
L314 2462587N72 2.2uH
L325 2480646Z20 2.20uH
L330 2462587N64 680nH
L331 2480646Z20 2.20uH
L332 2462587N53 100nH
L340 2462587V41 390nH
L400 2462587Q42 390nH
L401 2462587Q42 390nH
L410 2462587Q42 390nH
L411 2462587Q42 390nH
L505 2462587Q42 390nH
P100 3905643V01 Ground Contact Finger
PB501 4080523Z01 Tactile Push Button
PB502 4080523Z01 Tactile Push Button
PB503 4080523Z01 Tactile Push Button
PB504 4080523Z01 Tactile Push Button
PB505 4080523Z01 Tactile Push Button
Q110 4802245J55 RF Power Fet
Q111 4802245J50 Dual NPN/PNP
Q210 4802245J50 Dual NPN/PNP
Q241 4805218N63 NPN
Q260 4802245J50 Dual NPN/PNP
Q261 4802245J50 Dual NPN/PNP
Q301 4802245J44 NPN
Q302 4802245J44 NPN
Q315 4880214G02 NPN
Q320 4805218N63 NPN
Q400 4809579E18 MOSFET P-Chan
Q403 4880214G02 NPN
Q405 4802245J54 Dual NPN
Q410 4802245J54 dual NPN
Q416 4809579E18 MOSFET P-Chan
Q417 4802245J50 Dual NPN/PNP
Q502 5180159R01 Dual NPN
Q505 4880214G02 NPN
R101 0662057A34 240
R102 0680735Z01 0.075
R103 0662057M41 43
R104 0662057N15 47K
R106 0662057M26 10
Circuit
Ref
Motorola Part
No.
Description
R108 0662057M92 5.6K
R109 0662057N30 200K
R110 0662057M61 300
R111 0662057M33 20
R112 0662057M61 300
R120 0662057N14 43K
R130 0662057M98 10K
R131 0662057N05 18K
R132 0662057N33 270K
R161 0662057M57 200
R170 0662057A34 240
R171 0662057N14 43K
R172 0662057A32 200
R173 0662057N29 180K
R201 0662057N21 82K
R202 0662057N23 100K
R204 0662057N15 47K
R231 0662057M52 120
R232 0662057M69 620
R233 0662057M68 560
R241 0662057M32 18
R242 0662057M57 200
R243 0662057M98 10K
R244 0662057N01 12K
R245 0662057M59 240
R248 0662057M37 30
R251 0662057M32 18
R252 0662057M62 330
R253 0662057M95 7.5K
R254 0662057M95 6.8K
R255 0662057M89 4.3K
R256 0662057M37 30
R260 0662057M74 1K
R300 0662057M82 2.2K
R301 0662057N23 100K
R302 0662057N23 100K
R303 0662057M74 1K
R304 0662057N01 12K
R305 0662057M67 0
R306 0662057N23 100K
R307 0662057N23 100K
R308 0662057M60 270
R309 0662057M32 18
R310 0662057M60 270
R311 0662057N10 30K
R312 0662057M83 2.4K
R313 0662057M62 330
R314 0662057M85 3K
R315 0662057N01 12K
R316 0662057A96 91K
R317 0662057M74 1K
R318 0662057A79 18K
R319 0662057A29 150
R320 0662057M74 1K
R321 0662057M83 2.4K
R322 0662057N30 200K
Circuit
Ref
Motorola Part
No.
Description
