9-292 VHF Circuit Board/Schematic Diagrams and Parts List (PCB 8486062B09)
C433 2113743L41 .01uF, 10%
C434 2113743M24 0.1uF, +80%/-20%
C435 2113743M24 0.1uF, +80%/-20%
C436 2113743N34 22pF
C437 2113743N34 22pF
C440 2113743G26 4.7uF, +80%/-20%
C441 2113743N50 100pF
C442 2113743E20 0.1uF, 10%
C443 2113928N01 0.1uF, 10%
C444 2113743N50
2311049A56
100pF (for UHF only)
4.7uF, 20%,10V (for VHF only)
C445 2113743N50 100pF
C447 2113928N01 0.1uF, 10%
C448 2113928N01 0.1uF, 10%
C449 2113743N50 100pF
C450 2113743M24 0.1uF, +80%/-20%
C451 2113743M08 .022uF, +80%/-20%
C452 2113743G26 4.7uF, +80%/-20%
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF, 10%
C471 2113743N50 100pF
C472 2113743N50 100pF
C473 2113743N50 100pF
C475 2113743H14 10uF, +80%/-20%
C476 2113928D08 10uF, +80%/-20%
C479 2113928N01 0.1uF, 10%
C480 2113928D08 10uF, +80%/-20%
C481 2113928N01 0.1uF, 10%
C482 2113928N01
0662057M01
0.1uF, 10%
0 (SUB on LS
+
Models Only)
C490 2113743N50 100pF
C491 2113743N50 100pF
C492 2113743N50 100pF
C493 2113743N50 100pF
C494 2113743N50 100pF
C495 2113743N50 100pF
C496 2113743N50 100pF
C497 2113743N50 100pF
C502 2311049A05 0.47uF, 10%; 25V
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 .01uF, 10%
C521 2113743L41 .01uF, 10%
C522 2113743L41 .01uF, 10%
C523 2113743L41 .01uF, 10%
CR3301 4802245J42 Ring Quad Diode
CR3302 4805129M96 SMBV1032
Circuit
Ref
Motorola Part
No.
Description
CR3303 4880154K03 Dual Common Anode Cathode
CR411 4802245J47 Schottky Diode
CR412 4802245J47 Schottky Diode
CR413 4802245J47 Schottky Diode
CR440 4813833C02 Dual Diode Common Cathode
CR501 4880107R01 Rectifier
CR503 4805729G49 LED Red/Yellow
D3270 4862824C01 Vara ctor
D3301 4802081B58 Diode Dual
D3302 4802081B58 Diode Dual
D3521 4880973Z02 Pin Diode
D3551 4880973Z02 Pin Diode
D3701 4802233J09 Triple Diode
D3702 4802233J09 Triple Diode
D3761 4862824C03 Varactor
D3821 4805649Q13 Dual Varactor
D3831 4805649Q13 Dual Varactor
D3832 4862824C01 Vara ctor
E400 2480640Z01 Ferrite Bead
E401 2480640Z01 Ferrite Bead
E402 2480640Z01 Ferrite Bead
E403 2480640Z01 Ferrite Bead
E404 2480640Z01 Ferrite Bead
E405 2480640Z01 Ferrite Bead
E406 2480640Z01 Ferrite Bead
E407 2480640Z01 Ferrite Bead
E408 2480640Z01 Ferrite Bead
E409 2480640Z01 Ferrite Bead
F501 6580542Z01 Fuse 3A
FL401 4870368G02 Osc Xtal 38.4 kHz
H3501 2680499Z01 HEATSINK
J3501 0180117S05 RF_JACK
J3502 0280519Z02 ANTENNA_NUT
J400 0905505Y04 40-pins Connector
J403 0905505Y02 20-pins Connector
L3200 2462587N68 1uH
L3202 2462587N68 1uH
L3221 2462587N68 1uH
L3270 2462587T15 100nH
L3271 2462587Q20 2.2uH
L3301 2462587T35 12nH
L3303 2462587T35 12nH
L3304 2462587T23 470nH
L3305 2462587T35 12nH
L3306 2462587T35 12nH
L3308 2462587T34 10nH
L3309 2462587N55 150nH
L3312 2462587V28 33nH
L3501 2413926H09 5.6nH
L3503 2462587V32 68nH
L3504 2462587N51 68nH
L3511 2462587N44 18nH
L3512 2460591B04 11.03nH
L3513 2460591A11 7.66nH
L3515 2460591C23 13.85nH
L3518 2462587N48 39nH
Circuit
Ref
Motorola Part
No.
Description
L3519 2484657R01 BEAD
L3521 2460591A11 7.66nH
L3522 2460591E24 23.75nH
L3523 2462587N68 1uH
L3531 2460591N36 43.67nH
L3532 2460591N36 43.67nH
L3538 2460591M36 30.54nH
L3551 2460591N36 43.67nH
L3552 2460591A11 7.66nH
L3701 2462587Q42 390nH
L3731 2462587Q20 2.2uH
L3801 2462587V34 100nH
L3809 2462587V27 27nH
L3811 2462587V34 100nH
L3812 2462587V34 100nH
L3813 2462587Q47 1uH
L3816 2462587V34 100nH
L3821 2462587N50 56nH
L3822 2462587N49 47nH
L3823 2462587N49 47nH
L3824 2462587N68 1uH
L3825 2462587V34 100nH
L3826 2462587N68 1uH
L3831 2462587N50 56nH
L3832 2462587N51 68nH
L3833 2462587N50 56nH
L3834 2462587N68 1uH
L400 2462587Q42 390nH, 10%
L401 2462587Q42 390nH, 10%
L410 2462587Q42 390nH, 10%
L411 2462587Q42 390nH, 10%
L505 2462587Q42 390nH, 10%
PB501 4080523Z01 Tactile, Pushbutton
PB502 4080523Z01 Tactile, Pushbutton
PB503 4080523Z01 Tactile, Pushbutton
PB504 4080523Z01 Tactile, Pushbutton
PB505 4080523Z01 Tactile, Pushbutton
Q3200 4813827A07 MMBR941
Q3201 4880214G02 NPN
Q3202 4880214G02 NPN
Q3270 4805218N63 BFQ67W
Q3301 4880214G02 NPN
Q3302 4813827A07 NPN
Q3501 4802245J55 RF Power FET
Q3721 4802245J50 UMC5N
Q3801 4813827A07 NPN
Q400 4809579E18 MOSFET P-Chan
Q403 4880214G02 NPN
Q405 4802245J54 Dual NPN
Q410 4802245J54 Dual NPN
Q416 4809579E18 MOSFET P-Chan
Q417 4802245J50 Dual NPN/PNP
Q502 5180159R01 Dual NPN
Q505 4880214G02 NPN
R3200 0662057M54 150
R3201 0662057M82 2.2K
Circuit
Ref
Motorola Part
No.
Description
R3202 0662057M90 4.7K
R3203 0662057M98 10K
R3204 0662057M34 22
R3205 0662057M74 1K
R3206 0662057N23 100K
R3207 0662057N13 39K
R3208 0662057M50 100
R3209 0662057M74 1K
R3210 0662057M82 2.2K
R3211 0662057M82 2.2K
R3212 0662057M90 4.7K
R3213 0662057M82 2.2K
R3214 0662057M50 100
R3215 0662057M50 100
R3218 0662057M26 10
R3219 0662057M50 100
R3220 0662057M90 4.7K
R3221 0662057M50 100
R3224 0662057M26 10
R3225 0662057M74 1K
R3226 0662057M26 10
R3270 0662057M74 1K
R3271 0662057M42 47
R3272 0662057N15 47K
R3273 0662057N15 47K
R3274 0662057M74 1K
R3275 0662057M88 3.9K
R3276 0662057N30 200K
R3303 0662057N23 100K
R3304 0662057N23 100K
R3305 0662057N15 47K
R3306 0662057M82 2.2K
R3307 0662057N11 33K
R3308 0662057M78 1.5K
R3309 0662057M92 5.6K
R3310 0662057M98 10K
R3311 0662057M26 10
R3312 0662057M38 33
R3313 0662057M34 22
R3314 0662057M26 10
R3315 0662057M62 330
R3316 0662057M66 470
R3317 0662057N23 100K
R3318 0662057M66 470
R3321 0662057M54 150
R3322 0662057M58 220
R3323 0662057M32 18
R3324 0662057M74 1K
R3501 0662057M61 300
R3502 0662057M32 18
R3503 0662057M61 300
R3505 0662057M66 470
R3512 0662057A27 120
R3513 0662057A25 100
R3519 0680539Z01 0.1
R3542 0662057M92 5.6K
Circuit
Ref
Motorola Part
No.
Description
