Motorola HT Series User Manual

9-332 VHF Circuit Board/Schematic Diagrams and Parts List (PCB 8486473Z03)
VHF (136-174 MHz) Radio Parts List (PCB
8486473Z03)
Circuit
Ref
Motorola Part
No.
Description
B501 0986237A02 Connector (Contact Battery)
B503 3980502Z01 Backup Contact, B+
B504 3980501Z01 Backup Contact, B-
C3200 2113743N12 2.7pF
C3201 2113743N31 16pF
C3202 NOT PLACED -
C3203 2113743N37 30pF
C3205 2113743M24 100nF
C3206 2109445U26 9.1pF 1%
C3207 2113743N18 4.7pF
C3208 2113743M24 100nF
C3209 2113743M24 100nF
C3210 2113743M24 100nF
C3212 2311049A07 1uF
C3213 2311049A56 4.7uF
C3215 2113743N26 10pF
C3218 2311049A59 4.7uF
C3221 2113743E20 0.1uF
C3222 2113743M24 100nF
C3225 2113743M24 100nF
C3226 2113743M24 100nF
C3228 2113743M24 100nF
C3230 2113743M24 100nF
C3231 2113743M24 100nF
C3232 2113743M24 100nF
C3233 2113743M24 100nF
C3234 2113743M24 100nF
C3236 2113743L33 4700pF
C3238 2113743M24 100nF
C3274 2113743N37 30pF
C3275 2113743N35 24pF
C3278 2113743E20 0.1uF
C3279 2113743N52 120pF
C328 2113743M24 100nF
C3301 2113743N20 5.6pF
C3302 2113743N54 150pF
C3303 2113743N30 15pF
C3304 2113743N54 150pF
C3305 NOT PLACED -
C3306 2113928N01 0.1uF
C3307 2113743N50 100pF
C3308 2113743L05 330pF
C3309 2113928N01 0.1uF
C3310 NOT PLACED -
C3311 2113743N54 150pF
C3312 2113743N31 16pF
C3313 2113743N54 150pF
C3314 NOT PLACED -
C3315 2113743N26 10pF
C3316 2113743N14 3.3pF
C3317 2113743N37 30pF
C3318 2113743M08 22000pF
C3319 NOT PLACED -
C3320 2113743N48 82pF
C3321 2113743L05 330pF
C3322 2113743N50 100pF
C3323 2113743N50 100pF
C3324 2113743N38 33pF
C3325 2113743L17 1000pF
C3326 NOT PLACED -
C3327 2113743L05 330pF
C3329 2113743L05 330pF
C3330 2113743N50 100pF
C3331 2113743N50 100pF
C3332 2113743N40 39pF
C3334 2113743N33 20pF
C3335 2113743N34 22pF
C3336 2311049A96 33uF
C3337 2113743M08 22000pF
C3338 2113743L09 470pF
C3339 2113743N26 10pF
C337 2113928P04 1uF
C3501 2113743L05 330pF
C3502 2113743N38 33pF
C3503 2113743N38 33pF
C3504 2113743M08 22000pF
Circuit
Ref
Motorola Part
No.
Description
C3505 2113743N38 33pF
C3508 2113743M08 22000pF
C3509 2113743L05 330pF
C3512 2113740F43 47pF
C3513 2113740F38 30pF
C3514 2113740F47 68pF
C3515 2113743L29 3300pF
C3516 2311049A08 1uF
C3517 2113740F47 68pF
C3518 NOT PLACED
C3519 NOT PLACED
C3521 2111078B51 220pF
C3523 2111078B44 120pF
C3524 2113740F34 20pF
C3525 2113740F27 10pF
C3526 2113743M08 22000pF
C3527 NOT PLACED
C3528 2113740F27 10pF
C3531 2113740F34 20pF
C3532 2113740F47 68pF
C3533 2113740F24 7.5pF
C3534 2113740F19 4.7pF
C3535 2113740F37 27pF
C3536 2113740F31 15pF
C3537 2113740F33 18pF
C3539 2113740F29 12pF
C3541 2113743M08 22000pF
C3542 2113743L05 330pF
C3543 2113743M08 22000pF
C3544 2113743L05 330pF
C3546 2113743L05 330pF
C3547 2113743M08 22000pF
C3550 2113743N23 7.5pF
C3551 2113743N46 68pF
C3552 2113743N44 56pF
C3560 2311049A07 1uF
C3561 2113743M08 22000pF
C3562 2113743L29 3300pF
C3563 2113743L29 3300pF
Circuit
Ref
Motorola Part
No.
Description
C3564 2113743L01 220pF
C3565 2113743E07 0.022uF
C3566 2113743N50 100pF
C3567 2113743L05 330pF
C3568 2113743L29 3300pF
C3569 2113743M08 22000pF
C3570 2113743L05 330pF
C3571 2113743L09 470pF
C358 2113743N22 6.8pF
C359 2113743N31 16pF
C3701 2113743L41 10000pF
C3702 2113743L41 10000pF
C3703 2113743L41 10000pF
C3704 2113743L41 10000pF
C3705 2113743E20 0.1uF
C3706 2311049J11 4.7uF
C3707 2113743N34 22pF
C3708 2113928N01 0.1uF
C3709 2113928N01 0.1uF
C3710 2104993J02 2.2uF
C3711 2311049A69 10uF
C3712 2113928N01 0.1uF
C3713 2311049A09 2.2uF
C3714 2311049J11 4.7uF
C3715 2113743L09 470pF
C3721 2113743E20 0.1uF
C3722 2113743E20 0.1uF
C3724 2311049A08 1uF
C3725 NOT PLACED
C3726 2113743N24 8.2pF
C3727 2113743N50 100pF
C3731 2113743L41 10000pF
C3732 2113743L41 10000pF
C3733 2104993J02 2.2uF
C3734 2113743L41 10000pF
C3741 NOT PLACED
C3742 2113743L01 220pF
C3743 2113743L01 220pF
C3744 2113743L01 220pF
Circuit
Ref
Motorola Part
No.
Description
