Motorola HT Series User Manual

VHF Circuit Board/Schematic Diagrams and Parts List (PCB 8486473Z03) 9-335
R3561 0662057N01 12K
R3562 0662057N11 33K
R3563 0662057N33 270K
R3564 0662057N35 330K
R3565 NOT PLACED -
R3566 NOT PLACED -
R3569 0662057M92 5600
R3570 0662057M98 10K
R3571 0662057A27 120
R3572 0662057A27 120
R3573 0662057A27 120
R370 NOT PLACED -
R3701 0662057M50 100
R3702 NOT PLACED -
R3703 0662057M54 150
R3704 0662057M54 150
R3705 0662057N11 33K
R371 0662057N23 100K
R372 0662057N28 160K
R3721 0662057M66 470
R3722 0662057M68 560
R3723 0662057M50 100
R3726 NOT PLACED -
R3727 0662057N23 100K
R373 NOT PLACED -
R374 0662057N23 100K
R3741 0662057M50 100
R375 NOT PLACED -
R3751 0662057N30 200K
R3752 0662057N29 180K
R376 0662057M01 0
R3761 0662057N15 47K
R3762 NOT PLACED -
R377 0662057N23 100K
R378 0662057N23 100K
R3801 NOT PLACED -
R3802 0662057M50 100
R3803 0662057M58 220
R3804 0662057M98 10K
Circuit
Ref
Motorola Part
No.
Description
R3805 0662057N08 24K
R3806 0662057M34 22
R3807 NOT PLACED -
R3808 0662057M26 10
R3811 0662057M50 100
R3812 NOT PLACED -
R3816 0662057M74 1000
R3817 0662057M01 0
R3818 NOT PLACED -
R3821 0662057M58 220
R3822 0662057M42 47
R3823 0662057N11 33K
R3824 0662057N07 22K
R3825 0662057M38 33
R3826 0662057M32 18
R3828 0662057M50 100
R3829 0662057M01 0
R3830 NOT PLACED -
R3831 0662057M98 10K
R3832 0662057N01 12K
R3833 0662057M58 220
R3834 0662057M42 47
R3835 0662057N15 47K
R3836 0662057M98 10K
R400 0662057N15 47K
R401 0662057M01 0
R402 NOT PLACED -
R403 NOT PLACED -
R405 0662057M01 0
R406 0662057N20 ‘75K
R407 0662057N19 68K
R408 NOT PLACED -
R409 0662057M98 10K
R410 0662057N23 100K
R411 0662057M98 10K
R413 0662057M01 0
R414 0662057V34 180K 1%
R415 0662057V26 91K 1%
R416 0662057M98 10K
Circuit
Ref
Motorola Part
No.
Description
R418 0662057M01 0
R419 0662057M67 510
R420 0662057B46 10M
R421 0662057M81 2000
R423 0662057N21 82K
R424 0662057N12 36K
R425 0662057N10 30K
R426 0662057N35 330K
R427 0662057M84 2700
R428 0662057M10 2.2’
R429 0662057N20 ‘75K
R431 0662057N39 470K
R432 0662057N16 51K
R434 0662057M62 330
R435 0662057M81 2000
R436 0662057M01 0
R437 NOT PLACED -
R445 0662057N08 24K
R447 0662057N23 100K
R448 0662057M98 10K
R449 0662057N08 24K
R450 0683962T45 68
R451 0662057N03 15K
R452 0662057N23 100K
R453 NOT PLACED -
R454 NOT PLACED -
R455 NOT PLACED -
R456 0662057M01 0
R457 0662057M98 10K
R460 0662057M90 4700
R461 0662057M56 180
R462 0662057M98 10K
R463 0662057M61 300
R471 0662057N06 20K
R472 0662057M93 6200
R473 0662057M26 10
R475 0662057M01 0
R476 0662057N35 330K
R477 0662057M74 1000
Circuit
Ref
Motorola Part
No.
Description
R478 0662057M98 10K
R481 0662057N08 24K
R492 0662057M01 0
R498 0662057M98 10K
R499 0662057M98 10K
R501 0662057M70 680
R502 0662057M56 180
R505 0662057M98 10K
R506 0662057N15 47K
RT3301 NOT PLACED -
RT400 0680590Z01 Thermistor 33K
S501 4080710Z09 Frequency Switch
S502 1880619Z02 Volume/on-off Switch
SH3202 2686539Z01 IFIC Shield
SH3203 2686527Z01 Crystal Filter Shield
SH3301 2686081B01 RX Frontend bottom Shield
SH3302 2686081B05 Mixer Shield
SH3303 2686081B06 RX Frontend top Shield
SH3501 2686081B03 Harmonic Filter Shield
SH3502 2686081B04 PA Driver Shield
SH3701 2680511Z01 Synthesizer top Shield
SH3702 2680511Z01 Synthesizer bottom Shield
SH3801 2680513Z01 VCO top shield
SH3802 2680514Z01 VCO Bottom Shield
SH400 2680505Z01 Controller Memory Shield
SH401 2680506Z01 Controller on-off Shield
SH402 2680515Z01
Controller Microprocessor
Shield
SH403 2680516Z01 Controller Asfic Shield
T3301 2580541Z02 Transformer
T3302 2580541Z02 Transformer
U303 5113818A01 Dual Op Amp
U3201 5102463J58 3.3V Regulator
U3220 5186144B01 IF IC
U3221 5109522E10 Inverter IC
U3501 5185130C65 LDMOS Driver IC
U3502 5185765B26 PCIC
U3503 5185963A15 Temperature Sensor
U3701 5185130C18 LV FRAC-N IC
Circuit
Ref
Motorola Part
No.
Description

Motorola HT Series Specifications

General

Battery Type	Li-Ion
Waterproof	IP54
Operating Temperature	-30°C to +60°C
Frequency Range	VHF: 136-174 MHz
Number of Channels	16
