Motorola HT1250-LS+

4-2 Transceiver Performance Testing
Figure 4-1. Radio Side Button Location
Figure 4-2. Two-Line Display
9. Press any of the 18 front panel buttons, the three programmable side buttons, the side
PTT button, or the top orange button. A good button press will produce a single beep
when pressed and another beep when released.
10. Rotate the On/Off/Volume control or Channel/Talkgroup/Zone/Menu knob in either
direction. A series of beeps indicates proper operation.
11. Press ‘side button 2’ for 3 seconds in the front panel test mode to return the radio to the
RF Test mode.
12. Turn radio off to exit test mode.
Side Button 2
Side Button 3
On/Off/Volume
Knob
Side Button 1
(programmable)
(programmable)
(programmable)
Channel, Talkgroup,
Zone or Menu Selector
Knob
Annunciators
Exit Up Menu/Select
(+ u
<?>
Left Down Right
Figure 4-3. Menu Key Identification
