Motorola HT1250-LS+

4-4 Transceiver Performance Testing
4.3 Test Frequencies
The radio channels and test frequencies are listed in Table 4.3. The channels are selected using the
channel selector switch located on top of the radio, as shown in Figure 4-1. The test environment and
channel spacing for any particular frequency is selected using ‘side buttons 1 and 2’, as listed in
Tables 4-1 and 4-2. The radio shows the selected parameters on the radio display, and sounds the
corresponding number of beeps and tones listed in Table 4-1.
Table 4-3. Test Frequencies (Using the Channel Selector Switch)
Channel
Selector Switch
Position
Test Channel 200 MHZ 700 MHz
1 Low Power
8 High Power
TX #1 or #8
RX #1 or #8
217.025 MHz
217.025 MHz
746.125 MHz
746.125 MHz
2 Low Power
9 High Power
TX #2 or #9
RX #2 or #9
217.975 MHz
217.975 MHz
746.975 MHz
746.975 MHz
3 Low Power
10 High Power
TX #3 or #10
RX #3 or #10
219.125 MHz
219.125 MHz
762.125 MHz
762.125 MHz
4 Low Power
11 High Power
TX #4 or #11
RX #4 or #11
219.775 MHz
219.775 MHz
763.975 MHz
763.975 MHz
5 Low Power
12 High Power
TX #5 or #12
RX #5 or #12
220.525 MHz
220.525 MHz
776.525 MHz
763.975 MHz
6 Low Power
13 High Power
TX #6 or #13
RX #6 or #13
221.275 MHz
221.275 MHz
792.025 MHz
763.975 MHz
7 Low Power
14 High Power
TX #7 or #14
RX #7 or #14
221.975 MHz
221.975 MHz
793.975 MHz
763.975 MHz
