Motorola HT1250-LS+

5-4 Radio Tuning, Programming, Cloning, PassPort Tone Options and Diagnostic Functions
6. When cloning is completed, both radios reset themselves and turn their green LEDs off. The
source radio produces a “clone-exit” tone and displays “Clone Complete”.
7. Turn both radios off.
8. Disconnect the cloning cable from both radios and turn them on for normal operation.
Figure 5-3. Radio Side Button Locations
5.4.2 Error Codes
● “ERR: Mismatch” - The model numbers or the code plug versions are not the same for both
radios. Cloning cannot be performed.
● “ERR: Timeout” - Communication between the two radios was not established or was disrupted
during the cloning process. If this occurs, check the cloning cable and all connections. Repeat the
cloning procedure.
Side Button 1
Side Button 2
Side Button 3
On/Off
Knob
(programmable)
(programmable)
(programmable)
