8-4 Model Chart and Test Specifications
Transmitter
Specification 200 MHz 700 MHz
Power Output NiMH @ 7.5V: 1 or 5 W 1 or 2.5 W
Conducted and Radiated Emission: -16 dBm -16 dBm
(except -40 dBm from
1559-1610 MHz)
Adjacent Channel Coupled Power: N/A Complies with 47 CFR 27.53 (d) (1)
Audio Response:
(from 6 dB/oct. Pre-Emphasis, 300 to 3000 Hz): +1 to -3 dB
Audio Distortion:
@ 1000 Hz, 60%
Rated Max. Dev. 3% Typical
Modulation Limiting: ±2.5 kHz
FM Hum and Noise: -40 dB typical
FM Modulation Designator: 11K0F3E
Receiver
Specification 200 MHz 700 MHz
Sensitivity (12 dB SINAD): 0.3 µV
(0.25 µV Typical)
0.35 µV
(0.3 µV Typical)
Intermodulation: 70 dB
Adjacent Channel Selectivity: 60 dB (EIA/TIA 603)
40 dB (EIA/TIA 603A)
Spurious Rejection: 70 dB
Rated Audio: 0.5 W
Audio Distortion @ Rated Audio: 3% Typical
Hum and Noise: -40 dB
Audio Response
(from 6 dB/oct. De-Emphasis, 300 to 3000 Hz):
+1 to -3 dB
Conducted Spurious Emission per FCC Part
15:
-57 dBm <1 GHz
-47 dBm >1 GHz
Specifications subject to change without notice. All electrical specifications and methods refer to EIA/TIA 603 standards. PRO Series radios meet or
exceed requirements of MIL STD 810 C, D, E.
