Motorola MBP18 User Manual

Overview of Your Baby Unit
Important guidelines for installing your Baby Monitor
• To use your Video Monitor Baby and Parent Units together, you must
be able to establish a radio link between them, and the range will be
affected by environmental conditions.
• Any large metal object, like a refrigerator, a mirror, a filing cabinet,
metallic doors or reinforced concrete between the Baby and Parent
Unit may block the radio signal.
• The signal strength may also be reduced by other solid structures, like
walls, or by radio or electrical equipment, such as TVs, computers,
cordless or mobile phones, fluorescent lights or dimmer switches.
• Use of other 2.4GHz products, such as wireless networks (WiFi
®
routers), Bluetooth
®
systems, or microwave ovens, may cause
interference with this product, so keep the baby monitor away at least 5ft
(1m) from these types of products, or turn them off if they appear to be
causing interference.
• If the signal is weak, try moving the Parent and/or the Baby Unit to
different positions in the rooms.
1. ON/OFF Switch 6. Power LED
2. Pair Key 7. Infrared LEDs
3. Microphone 8. Power Adapter Connector
4. Photo Sensor (Night Vision Mode)
5. Camera Lens
1
2
3
5
6
7
8
4

Motorola MBP18 Specifications

General

Maximum range	160 m
Smartphone support	-
Brightness adjustment	Yes
Number of brightness levels	8
Product color	Black, White
Interface	RF
Frequency band	2.4 - 2.48 GHz
LED type	IR
Sensor type	CMOS
Digital zoom	2 x
Fixed aperture	2.5 mm
Fixed focal length	2.8 mm
Display diagonal	1.8 \
Display number of colors	262144 colors
AC input voltage	100-240 V
Power consumption	500 mA
Power source type	DC
AC input frequency	50 - 60 Hz
