Appendix A Specifications
MC21XX and Accessory Technical Specifications
Table A-1 summarizes the MC21XX technical specifications and intended operating environments.
Table A-1
MC21XX Technical Specifications
Item Description
Physical Characteristics
Dimensions 171.7 mm L x 60.9 mm W x 34.1 mm D
(6.76 in L x 2.40 in W x 1.24 in D)
Weight (including battery) MC2100: 228 g (8.04 oz)
MC2180: 236 g (8.32 oz)
Display 2.8 inch TFT Color QVGA (240 x 320) display with backlight
Touch Panel Analog resistive touch (MC2180 only)
Backlight LED backlight
Battery Rechargeable Lithium-ion 2400 mAh minimum (3.7V)
Expansion Slot User accessible microUSB slot (located under battery); up to 32 GB.
Network Connections Full-speed USB (host or client)*
Bluetooth (MC2180 only)
WLAN (MC2180 only)
*USB available with appropriate cables only
Notification LED and audible alert
Keypad Options 27-key Numeric
Audio Speaker and microphone (MC2180 only)
Beeper (MC2100 only)
