Handstrap
Figure 6-11 Handstrap
Installation
To install the handstrap:
1. Feed both loops through the mounting slots.
Figure 6-12 Feed Loops Through Mounting Slots
2. Slide each loop over the strap tab and push all the way down.
Belt
Buckle
Mini Stylus Holder
Loop
Loop Material
Hook Material
Loop
Strap Tab
Mounting Slots
