Specifications A - 3
Wireless PAN (MC2180 only)
Bluetooth v2.0 with Enhanced Data Rate (EDR); integrated antenna
Data Capture Specifications
Options Linear imager
1D laser scanner
2D imager
Linear Imager Specifications
Optical Resolution 5 mil minimum element width
Roll ± 25° from vertical
Pitch Angle ± 65° from normal
Skew Tolerance ± 50° from normal
Ambient Light Sunlight - 9,690 Lux
Artificial Light - 4,845 Lux
Scan Rate 50 scans/sec
Scan Angle 53.3° ± 3°
1D Laser Scanner Specifications
Optical Resolution 5 mil minimum element width
Roll ± 35° from vertical
Pitch Angle ± 65° from normal
Skew Tolerance ± 40° from normal
Ambient Light Sunlight - 107,640 Lux
Artificial Light - 4,844 Lux
Scan Rate 104 (± 12) scans/sec (bidirectional)
Scan Angle 47° (typical)
2D Imager Engine Specifications
Field of View Horizontal: 39.2°
Vertical: 25.4°
Optical Resolution 752 H x 480 V pixels (gray scale)
Roll
360°
Pitch Angle ± 60° from normal
Skew Tolerance ± 60° from normal
Table A-1 MC21XX Technical Specifications (Continued)
Item Description
