A - 2 MC45 User Guide
Operating System
Microsoft
®
Windows Embedded Handheld™ 6.5.3 Professional Edition
Memory 256 MB RAM / 1GB Flash
Interface/Communications USB 2.0
Output Power USB: 5 VDC @ 300mA max.
User Environment
Operating Temperature -10°C to 50°C (14°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 32°F to 104°F / 0° C to 40° C
Humidity 5% to 95% non-condensing
Drop Specification Multiple 1.5 m (5 ft.) drop per MIL-STD 810G
Multiple 0.9 m (3 ft.) drop to concrete, over operating temperature range
Tumble 250, 0.5 m (1.5 ft.) tumbles with standard batteries installed; per applicable IEC
tumble specifications
Electrostatic Discharge (ESD) +/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect discharge
Sealing IP64 per applicable IEC sealing specifications
Vibration .04g2/Hz Random, Non-Operating, 1 hour duration per axis
Termal Shock -40°C to 70°C rapid transition
Wireless WAN Data and Voice Communications
Radio GSM and UMTS/HSDPA
Frequency Band GSM – All Models Quad Band : 850 / 900 / 1800 / 1900 MHz
UMTS/HSDPA – MC4597-A and MC4587-A : 2100 MHz
UMTS/HSDPA – MC4597-B: 850 / 1900 MHz
GPS Integrated, Autonomous and Assisted-GPS (A-GPS)
Wireless LAN Data and Voice Communications
Radio
MC4597-A and MC4597-B: Tri-mode IEEE
®
802.11a/b/g
Data Rates Supported 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
Operating Channels Chan 8-169 (5040 – 5845 MHz)
Chan 1-13 (2412-2472 MHz) Chan 14 (2484 MHz) Japan only
Actual operating frequencies depend on regulatory rules and certification
agency
Table A-1
MC45 Technical Specifications (Continued)
Item Description
