Appendix B Keypads
Numeric Keypad Configuration
The numeric keypad contains application keys, scroll keys, and function keys. The keypad is color-coded to
indicate the alternate function key (blue) values. Note that an application can change keypad functions so the
MC45’s keypad may not function exactly as described. See Table B-1 for key and button descriptions and Table
B-2 on page B-4 for the keypad’s special functions.
Figure B-1
MC45 Numeric Keypad
