Page 5 of 10
PIN
Signal Name
Function
1
USB_GND
USB
2
USB_D_PLUS
USB
3
TXD
RS232C
4
RXD
RS232C
5
DCD
RS232C
6
RTS
RS232C
7
DSR
RS232C
8
GND
Ground, 2.5A max
9
RI
RS232C
10
CRADLE_DET
Grounded by cradle when in cradle
11
DTR
RS232C
12
Not
connected Not connected
13
POWER_IN
12V, 2.5A max
14
CTS
RS232C
15
USB_5V_DET
USB
16
USB_D_MINUS
USB
17
EXT_PWR_OUT
500mA max
Table 1: MC9190 Bottom Port Pin-Outs

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Motorola MC9190 and is the answer not in the manual?

Motorola MC9190 Specifications

General IconGeneral
RAM256 MB
Flash Memory1 GB
Scanner1D laser scanner or 2D imager
SealingIP64
Operating Temperature-4° F to 122° F/-20° C to 50° C
ProcessorMarvell PXA320 @ 806 MHz
Display3.7 inch VGA color display
Connectivity802.11a/b/g, Bluetooth
Battery2200 mAh Lithium-ion
Drop Spec6 ft./1.8 m drop to concrete across operating temperature range
Weightwith battery
Keypad28-key numeric, 43-key alphanumeric, 53-key alphanumeric
