19
Status Icons
Status icons appear when your phone is engaged in certain
activities or when you have activated certain features.
Status Icon Description
Trunked Mode Operation
Signal Strength (TMO)
Allows you to check signal strength. More bars
indicate a stronger signal.
No Service
Scan
Indicates scanning is activated in the MTP850.
Data Connected
Displayed when the MTP850 is successfully
connected to an external device and ready for
data transfer.
Data Transmit/Receive
Displayed when the MTP850 is transferring data
to/receiving data from the external device (laptop
or desktop PC).
No number – standby data session.
Number 1, 2, 3, or 4 – indicates active data
session with 25%, 50%, 75%, or 100% bandwidth.
Direct Mode Operation
Signal Strength (DMO)
Indicates an incoming Direct Mode Group Call.
Direct Mode
Displayed when the MTP850 is in Direct Mode.
Repeater Mode
Displayed when the terminal is switched to work
as a repeater in Repeater mode.
