Annotation Description
15 Top Microphone
Activated during Simplex, high audio calls such as Group Calls.
16 Display
Features a high resolution of 240 x 320 pixels and 262,144 colors. Supports
scalable fonts and high color images.
17 Side Connector
Provides connection for accessories. You can connect the following cables:
• Boot Programming / USB Data Cable Ex, PMKN4158_
• Serial Data Cable Ex, PMKN4159_
• USB Data Cable Ex, PMKN4160_
• E2EE KVL Cable Ex, PMKN4161_
NOTICE: It is recommended to turn off the radio before connecting
accessories.
18 Menu key
• From the home screen, press to enter the main menu.
• Used to enter context-sensitive menus.
19 Speaker
20 On/Off/End/Home key
• Press and hold to turn on/off your radio.
• Press to end calls.
• Press to return to the home screen.
21 Navigation key
Press Up, Down, Left, or Right Navigation key for list scrolling, while moving
around the menu hierarchy, or for alphanumeric text editing.
From the home screen, press to activate one of the following:
• Down Navigation key – enters Recent Calls menu item.
• Up Navigation key – changes My Groups talkgroup folder.
• Left and Right Navigation key – toggles through the talkgroups.
NOTICE: A detailed list of compatible accessories is included in Accessory Leaflet, part
number: MN002135A01. To obtain the document, contact your service provider.
2.4
Powering On the Radio
Procedure:
Press and hold On button.
Your radio performs a self-check and registration routine.
After successful registration, your radio is in service.
NOTICE: Your radio powers on without visible and audible notification if Covert Mode is
activated.
MN002041A01-AH
Chapter 2: Getting Started
34
