Motorola MVME162 - Table A-5. EIA-530 Interface Transmitter Characteristics; Table A-6. EIA-530 Interface Receiver Characteristics

EIA-530 Connections
MVME162/D2 A-7
A
Table A-5. EIA-530 Interface Transmitter Characteristics
Parameter
Value
Unit
Minimum Maximum
Differential output voltage (absolute, with 100Ω
load)
2.0 V
Open circuit differential voltage output (absolute) 6.0 V
Output offset voltage (with 100Ω load) 3.0 V
Short circuit output current (for any voltage between
-7V and +7V)
±180 mA
Power off output current (for any voltage between
-7V and +7V)
±100
µA
Output transition time (with 100Ω, 15pF load) 15 ns
Table A-6. EIA-530 Interface Receiver Characteristics
Parameter
Value
Minimum Maximum
Unit
Differential input voltage ±12 V
Input offset voltage ±12 V
Differential input high threshold voltage 200 mV
Differential input low threshold voltage -200 mV
Differential input hysteresis 50 mV
Input impedance (without termination resistors) 10 KΩ
