Motorola MVME162 - CHAPTER 1 GENERAL INFORMATION

MVME162/D21-1
1
GENERAL INFORMATION
Introduction
This manual provides general information, hardware preparation and
installation instructions, operating instructions, and a functional description
of the MVME162 Embedded Controller (referred to as the MVME162
throughout this manual).
Models
The MVME162 is available in several models, which are listed in Table 1-1.
Table 1-1. MVME162 Models
Model
Description
-001 MC68LC040 microprocessor, 1MB DRAM, 512KB SRAM
-002 MC68040 microprocessor, 1MB DRAM, 512KB SRAM
-003 MC68LC040 microprocessor, 1MB DRAM, 512KB SRAM, no VMEbus
-010 MC68LC040 microprocessor, 4MB DRAM, 512KB SRAM
-011 MC68LC040 microprocessor, 4MB DRAM, SCSI, 512KB SRAM
-012 MC68LC040 microprocessor, 4MB DRAM, Ethernet, 512KB SRAM
-013 MC68LC040 microprocessor, 4MB DRAM, SCSI, Ethernet, 512KB SRAM
-014 MC68LC040 microprocessor, 4MB DRAM, Ethernet, no VMEbus
-020 MC68040 microprocessor, 4MB DRAM, 512KB SRAM
-021 MC68040 microprocessor, 4MB DRAM, SCSI, 512KB SRAM
-022 MC68040 microprocessor, 4MB DRAM, Ethernet, 512KB SRAM
-023 MC68040 microprocessor, 4MB DRAM, SCSI, Ethernet, 512KB SRAM
-026 MC68040 microprocessor, 4MB DRAM, Ethernet, no VMEbus
-030 MC68LC040 microprocessor, 8MB DRAM, 512KB SRAM
-031 MC68LC040 microprocessor, 8MB DRAM, SCSI, 512KB SRAM
-032 MC68LC040 microprocessor, 8MB DRAM, Ethernet, 512KB SRAM
-033 MC68LC040 microprocessor, 8MB DRAM, SCSI, Ethernet, 512KB SRAM
-040 MC68040 microprocessor, 8MB DRAM, 512KB SRAM
-041 MC68040 microprocessor, 8MB DRAM, SCSI, 512KB SRAM
-042 MC68040 microprocessor, 8MB DRAM, Ethernet, 512KB SRAM
-043 MC68040 microprocessor, 8MB DRAM, SCSI, Ethernet, 512KB SRAM
