Motorola MVME162 - Table 3-12. TOD Clock Memory Map

Operating Instructions
3-20 User’s Manual
3
Note
W = Write Bit R = Read Bit S = Signbit
ST = Stop Bit FT = Frequency Test x = Unused
$FFFC1F3E - $FFFC1F45 Memory Mezzanine Serial Number 8
$FFFC1F46 - $FFFC1F4D Serial Port 2 Personality PWB 8
$FFFC1F4E - $FFFC1F55 Serial Port 2 Personality Serial No. 8
$FFFC1F56 - $FFFC1F5D IP_a Board ID 8
$FFFC1F5E - $FFFC1F65 IP_a Board Serial Number 8
$FFFC1F66 - $FFFC1F6D IP_a Board PWB 8
$FFFC1F6E - $FFFC1F75 IP_b Board ID 8
$FFFC1F76 - $FFFC1F7D IP_b Board Serial Number 8
$FFFC1F7E - $FFFC1F85 IP_b Board PWB 8
$FFFC1F86 - $FFFC1F8D IP_c Board ID 8
$FFFC1F8E - $FFFC1F95 IP_c Board Serial Number 8
$FFFC1F96 - $FFFC1F9D IP_c Board PWB 8
$FFFC1F9E - $FFFC1FA5 IP_d Board ID 8
$FFFC1FA6 - $FFFC1FAD IP_d Board Serial Number 8
$FFFC1FAE - $FFFC1FB5 IP_d Board PWB 8
$FFFC1FB6 - $FFFC1FF6 Reserved 65
$FFFC1FF7 Checksum 1
Table 3-12. TOD Clock Memory Map
Data Bits
Address D7D6D5D4D3D2D1D0 Function
$FFFC1FF8WRS---------- CONTROL
$FFFC1FF9 ST -- -- -- -- -- -- -- SECONDS 00
$FFFC1FFA x -- -- -- -- -- -- -- MINUTES 00
$FFFC1FFB x x -- -- -- -- -- -- HOUR 00
$FFFC1FFC x FT x x x -- -- -- DAY 01
$FFFC1FFD x x -- -- -- -- -- -- DATE 01
$FFFC1FFE x x x -- -- -- -- -- MONTH 01
$FFFC1FFF -- -- -- -- -- -- -- -- YEAR 00
Table 3-11. BBRAM Configuration Area Memory Map (Continued)
Address Range Description Size (Bytes)
