MVME162/D22-1
2
HARDWARE PREPARATION
AND INSTALLATION
Introduction
This chapter provides unpacking instructions, hardware preparation
guidelines, and installation instructions for the MVME162 Embedded
Controller. Hardware preparation for the MVME712 series transition
modules is described in separate manuals; refer to the Related Documentation
section in Chapter 1.
Unpacking Instructions
Note
If the shipping carton is damaged upon receipt, request that
the carrier’s agent be present during the unpacking and
inspection of the equipment.
Unpack the equipment from the shipping carton. Refer to the packing list and
verify that all items are present. Save the packing material for storing and
reshipping of equipment.
Caution
Avoid touching areas of integrated circuitry; static discharge
can damage circuits.
Hardware Preparation
To produce the desired configuration and ensure proper operation of the
MVME162, you may need to carry out certain modifications before installing
the module.
The MVME162 provides software control over most options: by setting bits in
control registers after installing the MVME162 in a system, you can modify its
configuration. (The MVME162 registers are described in Chapter 4, and/or in
the MVME162 Embedded Controller Programmer’s Reference Guide as listed in
Related Documentation in Chapter 1.)
Some options, however, are not software-programmable. Such options are
controlled by manual installation or removal of header jumpers or interface
modules.
