Motorola Professional GP340 - PCB 8485726 Z01 - Parts List

PCB 8485726Z01 - Parts List 4-11
3.0 PCB 8485726Z01 - Parts List
Circuit
Ref
Motorola
Part No.
Description
B501 0986237A02 CONNECTOR
(CONTACT BATTERY)
B503 3980502Z01 CONTACT, BACKUP B+
B504 3980501Z01 CONTACT, BACKUP B-
C101 2113740F51 CAP CHIP REEL CL1 +/-30 100
C102 2113740F28 CAP CHIP REEL CL1+/-30 11
C103 2113740F35 CAP CHIP REEL CL1 +/-30 22
C104 2113740F28 CAP CHIP REEL CL1+/-30 11
C105 2113743L05 CAP CHIP 330 PF 10% X7R
C106 2113740F22 CAP CHIP REEL CL1 +/-30 6.2
C107 2113740F15 CAP CHIP REEL CL1 +/-30 3.3
C108 2113743L05 CAP CHIP 330 PF 10% X7R
C109 2113740F51 CAP CHIP REEL CL1 +/-30 100
C110 2113743L05 CAP CHIP 330 PF 10% X7R
C111 2103689A47 SL240J HIGH - Q CAP, UCNO
C112 2180605Z35 HIGH Q CHIP CAPACITOR, 68PF
C114 2113743L05 CAP CHIP 330 PF 10% X7R
C117 2113743N42 CAP CHIP 47.0 PF 5% COG
C118 2113743N50 CAP CHIP 100 PF 5% COG
C119 2113743L05 CAP CHIP 330 PF 10% X7R
C120 2113743N30 CAP CHIP 15.0PF 5% COG
C121 2113743N50 CAP CHIP 100 PF 5% COG
C122 2113743L05 CAP CHIP 330 PF 10% X7R
C123 2311049A18 CAP. TANT 10% 10UF
C125 2113743N50 CAP CHIP 100 PF 5% COG
C126 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C127 2113743L17 CAP CHIP 1000 PF 10% X7R
C128 2113743M08 CAP CHIP 22000PF +80-20% Y5V
C129 2113743N35 CAP CHIP 24.0 PF 5% COG
C130 2113743L05 CAP CHIP 330 PF 10% X7R
C131 2113743M08 CAP CHIP 22000PF +80-20% Y5V
C132 2113743L05 CAP CHIP 330 PF 10% X7R
C133 2113743L17 CAP CHIP 1000 PF 10% X7R
C134 2113743L29 CAP CHIP 3300PF 10% X7R
C135 2113743M08 CAP CHIP 22000PF +80-20% Y5V
C138 2113743L05 CAP CHIP 330 PF 10% X7R
C150 2113743M08 CAP CHIP 22000PF +80-20% Y5V
C151 2113743L05 CAP CHIP 330 PF 10% X7R
C152 2113743M08 CAP CHIP 22000PF +80-20% Y5V
C160 2113743N50 CAP CHIP 100 PF 5% COG
C161 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C165 2113743N50 CAP CHIP 100 PF 5% COG
C166 2113743L05 CAP CHIP 330 PF 10% X7R
C169 2113743N34 CAP CHIP 22.0 PF 5% COG
C170 2113743L05 CAP CHIP 330 PF 10% X7R
C171 2113743L05 CAP CHIP 330 PF 10% X7R
C172 2113743E20 CAP CHIP. 10 UF 10%
C173 2113743M08 CAP CHIP 22000PF +80-20% Y5V
C174 2113743L05 CAP CHIP 330 PF 10% X7R
C188 2113743N50 CAP CHIP 100 PF 5% COG
C193 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C201 2113743L05 CAP CHIP 330 PF 10% X7R
C202 2113743L17 CAP CHIP 1000 PF 10% X7R
C203 2311049A56 CAP TAN CHIP A/P 4.7 20 10
C204 2104993J02 CAP MONO. CERAMIC (2.2UF)
C206 2113740F63 CAP CHIP CL1 +/-30 330 5%
C207 2113743N40 CAP CHIP 39.0 PF 5% COG
C210 2113743L05 CAP CHIP 330 PF 10% X7R
C211 2113743L05 CAP CHIP 330 PF 10% X7R
C212 2113743L05 CAP CHIP 330 PF 10% X7R
C213 2113743L05 CAP CHIP 330 PF 10% X7R
C214 2113743L05 CAP CHIP 330 PF 10% X7R
C217 2104993J02 CAP MONO. CERAMIC (2.2UF)
C218 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C219 2113743K16 CAP CHIP .220 UF +80-20% 16V
C220 2113743L05 CAP CHIP 330 PF 10% X7R
C223 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C224 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C228 2311049J11 CAPACITOR TANT 10% 4.7UF
C229 2113743L17 CAP CHIP 1000 PF 10% X7R
C230 2113743L05 CAP CHIP 330 PF 10% X7R
C231 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C232 2113743E12 CAP CHIP .047UF 10% X7R
C233 2311049A01 CAP TANT CHIP A/P .1 10 35
C234 2311049A05 CAP TANT 10% 0.47UF
C235 2104993J02 CAP MONO. CERAMIC (2.2UF)
C238 2113741F17 CAP CHIP CL2 X7R REEL 470
C241 2113743L05 CAP CHIP 330 PF 10% X7R
C242 2113743N25 CAP CHIP 9.1 PF +-.5PF COG
C243 2113743N26 CAP CHIP 10.0 PF 5% COG
C244 2113740F22 CAP CHIP REEL CL1 +/-30 6.2
C245 2113743N12 CAP CHIP 2.7 PF +-.25PF COG
C246 2113743L05 CAP CHIP 330 PF 10% X7R
C247 2113743L05 CAP CHIP 330 PF 10% X7R
C248 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C250 2113743N26 CAP CHIP 10.0 PF 5% COG
C251 2113743L05 CAP CHIP 330 PF 10% X7R
C252 2113743N27 CAP CHIP 11.0 PF 5% COG
C253 2113740F10 CAP CHIP REEL CL1+/-30 2.0
C254 2113743N12 CAP CHIP 2.7 PF +-.25PF COG
C255 2113743L05 CAP CHIP 330 PF 10% X7R
C256 2113743N27 CAP CHIP 11.0 PF 5% COG
C257 2113743L05 CAP CHIP 330 PF 10% X7R
C258 2113743L41 CAP CHIP 10000 PF 10% X7R
C259 2113743L41 CAP CHIP 10000 PF 10% X7R
C260 2113743L05 CAP CHIP 330 PF 10% X7R
C264 2113743L05 CAP CHIP 330 PF 10% X7R
C271 2113743N07 CAP CHIP 1.5PF +-.25PF COG
C273 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C276 2104993J02 CAP MONO. CERAMIC (2.2UF)
C277 2113743L05 CAP CHIP 330 PF 10% X7R
C278 2311049A09 TANT CAP 2.2 UF 10%
C279 2104993J02 CAP MONO. CERAMIC (2.2UF)
C281 2113743L05 CAP CHIP 330 PF 10% X7R
C285 2113743L05 CAP CHIP 330 PF 10% X7R
C286 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C289 2113743L05 CAP CHIP 330 PF 10% X7R
C291 2311049A69 CAP TAN CHIP 10.0 UF 20% 6.3V
C292 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C293 2113743A27 CAP CHIP .470 UF 10% 16V
Circuit
Ref
Motorola
Part No.
Description
C294 2113743L05 CAP CHIP 330 PF 10% X7R
C295 2113743N50 CAP CHIP 100 PF 5% COG
C296 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C297 2113743L41 CAP CHIP 10000 PF 10% X7R
C298 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C301 2113743N25 CAP CHIP 9.1 PF +-.5PF COG
C302 2113743N29 CAP CHIP 13.0 PF 5% COG
C303 2113740L10 CAP CER CHIP 4.7 PF +-0.1PF
C304 2113743N29 CAP CHIP 13.0 PF 5% COG
C305 2113743N25 CAP CHIP 9.1 PF +-.5PF COG
C306 2113743N25 CAP CHIP 9.1 PF +-.5PF COG
C307 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C308 2113743L05 CAP CHIP 330 PF 10% X7R
C309 2113743L05 CAP CHIP 330 PF 10% X7R
C310 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C312 2113743N25 CAP CHIP 9.1 PF +-.5PF COG
C313 2113743N29 CAP CHIP 13.0 PF 5% COG
C314 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C315 2113743L05 CAP CHIP 330 PF 10% X7R
C316 2113740L10 CAP CER CHIP 4.7 PF +-0.1PF
C317 2113743N29 CAP CHIP 13.0 PF 5% COG
C318 2113743N25 CAP CHIP 9.1 PF +-.5PF COG
C319 2113743N25 CAP CHIP 9.1 PF +-.5PF COG
C320 2113743N20 CAP CHIP 5.6 PF +-.5PF COG
C321 2113743L05 CAP CHIP 330 PF 10% X7R
C322 2113743N48 CAP CHIP 82.0 PF 5% COG
C323 2113743N54 CAP CHIP 150 PF 5% COG
C324 2113743N33 CAP CHIP 20.0 PF 5% COG
C325 2113743L41 CAP CHIP 10000 PF 10% X7R
C326 2113743L41 CAP CHIP 10000 PF 10% X7R
C327 2113743N50 CAP CHIP 100 PF 5% COG
C328 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C329 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C330 2113743N26 CAP CHIP 10.0 PF 5% COG
C331 2113743L05 CAP CHIP 330 PF 10% X7R
C334 2113743M08 CAP CHIP 22000PF +80-20% Y5V
C336 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C337 2113743N50 CAP CHIP 100 PF 5% COG
C338 2113743N30 CAP CHIP 15.0PF 5% COG
C339 2180478Z20 CAP MONO. CERAMIC (1.0UF)
C340 2180478Z20 CAP MONO. CERAMIC (1.0UF)
C341 2180478Z20 CAP MONO. CERAMIC (1.0UF)
C342 2180478Z20 CAP MONO. CERAMIC (1.0UF)
C343 2113743A23 CAP CHIP .220UF 10% X7R
C344 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C345 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C346 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C347 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C348 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C349 2113743E07 CER CHIP CAP .022UF
C350 2113743L05 CAP CHIP 330 PF 10% X7R
C351 2113743N33 CAP CHIP 20.0 PF 5% COG
C352 2113743N28 CAP CHIP 12.0 PF 5% COG
C353 2113743N41 CAP CHIP 43.0 PF 5% COG
C354 2113743N42 CAP CHIP 47.0 PF 5% COG
C355 2113743A24 CAP CHIP .330 UF 10% 16V
Circuit
Ref
Motorola
Part No.
Description
C356 2113743M08 CAP CHIP 22000PF +80-20% Y5V
C357 2113743A23 CAP CHIP .220UF 10% X7R
C358 2113741A23 CHIP CAPACITORS 1200PF +-5%
C359 2109720D14 CAP CER CHIP LOW DIST 0.1UF
C360 2113743E07 CER CHIP CAP .022UF
C361 2113741F49 CHIP CAP, CER 10NF
C362 2113743M08 CAP CHIP 22000PF +80-20% Y5V
C363 2311049A40 GLOBAL CAP TANT 10% 2.2 UF
C364 2113743L41 CAP CHIP 10000 PF 10% X7R
C370 2113743L05 CAP CHIP 330 PF 10% X7R
C371 2113743N24 CAP CHIP 8.2 PF + -.5PF COG
C374 2113743L05 CAP CHIP 330 PF 10% X7R
C375 2113743L05 CAP CHIP 330 PF 10% X7R
C380 2113743L41 CAP CHIP 10000 PF 10% X7R
C382 2311049A59 CAP TANT CHIP A/P 10UF 10% 6V
C383 2113743N50 CAP CHIP 100 PF 5% COG
C384 2113743N44 CAP CHIP 56.0 PF 5% COG
C385 2113743N44 CAP CHIP 56.0 PF 5% COG
C386 2113743L05 CAP CHIP 330 PF 10% X7R
C390 2113743N50 CAP CHIP 100 PF 5% COG
C395 2113743L05 CAP CHIP 330 PF 10% X7R
C397 2311049A07 CAP TANT 10% 1.0UF
C398 2113743N23 CAP CHIP 7.5 PF +-.5PF COG
C400 2113743L41 CAP CHIP 10000 PF 10% X7R
C401 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C402 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C403 2113928D08 CAP CERAMIC CHIP 10.0UF
C407 2113928N01 CAP CER CHIP 0.1UF 10% 6.3
C408 2113743N50 CAP CHIP 100 PF 5% COG
C409 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C410 2113928N01 CAP CER CHIP 0.1UF 10% 6.3
C411 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C414 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C415 2109720D01 CAP CER CHIP LOW DIS T .01UF
C416 2113928N01 CAP CER CHIP 0.1UF 10% 6.3
C420 2113743L41 CAP CHIP 10000 PF 10% X7R
C421 2113928N01 CAP CER CHIP 0.1UF 10% 6.3
C422 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C423 2113743N50 CAP CHIP 100 PF 5% COG
C424 2311049A59 CAP TANT CHIP A/P 10UF 10% 6V
C425 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C426 2113743N50 CAP CHIP 100 PF 5% COG
C427 2113743N50 CAP CHIP 100 PF 5% COG
C428 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C429 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C430 2113928N01 CAP CER CHIP 0.1UF 10% 6.3
C431 2113743N50 CAP CHIP 100 PF 5% COG
C433 2113743L41 CAP CHIP 10000 PF 10% X7R
C434 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C435 2113743M24 CAP CHIP 100000 PF +80-20% Y5V
C436 2113743N34 CAP CHIP 22.0 PF 5% COG
C437 2113743N34 CAP CHIP 22.0 PF 5% COG
C440 2113743G26 CAP CHIP 4.7UF 16V + 80-20%
C441 2113743N50 CAP CHIP 100 PF 5% COG
C442 2113743E20 CAP CHIP. 10 UF 10%
C443 2113928N01 CAP CER CHIP 0.1UF 10% 6.3
