Motorola Radius CM200

4-22 VHF 25–45 W Band 2 PCB 8486487Z03-B / Schematics
C5033 2113743K15 CAP, 0.1uF
C5034 2113743K15 CAP, 0.1uF
C5035 2113743K15 CAP, 0.1uF
C5036 2113743K15 CAP, 0.1uF
C5037 2113743K15 CAP, 0.1uF
C5038 2113743K15 CAP, 0.1uF
C5039 NOT PLACED CAP, 0.1uF
C5040 NOT PLACED CAP, 0.1uF
C5041 2113743F18 CAP, 2.2uF
C5042 2113743F16 CAP, 1uF
C5043 2113743F16 CAP, 1uF
C5044 2113928C04 CAP, 4.7uF
C5045 2113743F16 CAP, 1uF
C5046 2113743E20 CAP, 0.1uF
C5047 2113743E20 CAP, 0.1uF
C5048 2113743E20 CAP, 0.1uF
C5049 2113743E20 CAP, 0.1uF
C5050 2113743E20 CAP, 0.1uF
C5051 NOT PLACED CAP, 0.1uF
C5052 2113743E20 CAP, 0.1uF
C5053 NOT PLACED CAP, 0.1uF
C5054 NOT PLACED CAP, 0.1uF
C5055 2113928C04 CAP, 4.7uF
C5056 2113928C04 CAP, 4.7uF
C5057 2113928C04 CAP, 4.7uF
C5058 NOT PLACED CAP, 0.1uF
C5059 2113743E07 CAP, .022uF
C5060 2113741M69 CAP, 0.1uF
C5061 2113741M69 CAP, 0.1uF
C5062 2113741M69 CAP, 0.1uF
Circuit
Ref.
Motorola
Part No.
Description
C5063 2113741M69 CAP, 0.1uF
C5064 2113741F25 CAP, 1000pF
C5065 2113741F25 CAP, 1000pF
C5066 2113741F25 CAP, 1000pF
C5067 2113741F25 CAP, 1000pF
C5068 2113741F25 CAP, 1000pF
C5069 2113741F25 CAP, 1000pF
C5070 2113741F25 CAP, 1000pF
C5071 2113741F25 CAP, 1000pF
C5072 2113741F25 CAP, 1000pF
C5073 2113741F25 CAP, 1000pF
C5074 2113741F25 CAP, 1000pF
C5075 NOT PLACED CAP, 1000pF
C5076 2113741F25 CAP, 1000pF
C5077 2113741F25 CAP, 1000pF
C5078 2113741F25 CAP, 1000pF
C5079 2113741F25 CAP, 1000pF
C5080 2113741F25 CAP, 1000pF
C5081 2113741F25 CAP, 1000pF
C5082 2113741F25 CAP, 1000pF
C5083 2113740F51 CAP, 100pF
C5084 2113740F51 CAP, 100pF
C5085 2113741A53 CAP, .022uF
C5086 2113741A53 CAP, .022uF
C5087 2113740F53 CAP, 120pF
C5088 2113740F49 CAP, 82pF
C5089 2113740F49 CAP, 82pF
C5090 2113740F49 CAP, 82pF
C5091 2113740F49 CAP, 82pF
C5092 2113740F59 CAP, 220pF
Circuit
Ref.
Motorola
Part No.
Description
C5094 2113740F59 CAP, 220pF
C5095 2113740F59 CAP, 220pF
C5096 2113740F59 CAP, 220pF
C5097 2113740F59 CAP, 220pF
C5098 2113740F59 CAP, 220pF
C5099 2113740F59 CAP, 220pF
C5100 2113740F59 CAP, 220pF
C5101 NOT PLACED CAP, 1000pF
C5102 NOT PLACED CAP, 0.1uF
C5103 NOT PLACED CAP, 0.1uF
C5104 NOT PLACED CAP, 10uF
C5110 2113741F25 CAP, 1000pF
C5111 2113741F25 CAP, 1000pF
C5112 NOT PLACED CAP, 16pF
C5113 NOT PLACED CAP, 220pF
C5114 2113743F16 CAP, 1uF
C5115 NOT PLACED CAP, 6.8pF
C5116 NOT PLACED CAP, 220pF
C5117 NOT PLACED CAP, 16pF
C5118 2113743E20 CAP, 0.1uF
C5119 2113743H14 CAP, 10uF
C5120 NOT PLACED CAPP, 47uF
CR300 4880154K03 MMBD353, SCHOTTKY
COMM AK
CR301 4880154K03 MMBD353, SCHOTTKY
COMM AK
D100 NOT PLACED MMBD6100, DUAL
COMM CATH
D101 4813833C02 MMBD6100, DUAL
COMM CATH
D102 4813833C02 MMBD6100, DUAL
COMM CATH
Circuit
Ref.
Motorola
Part No.
Description
D103 4802482J02 MA4P959, PIN
D104 4802482J02 MA4P959, PIN
D105 4805218N57 RB715F, DUAL COMM
CATH
D106 4805218N57 RB715F, DUAL COMM
CATH
D107 4805218N57 RB715F, DUAL COMM
CATH
D108 4805218N57 RB715F, DUAL COMM
CATH
D200 4802233J09 IMN10, 3 DIODE ARRAY
D201 4802233J09 IMN10, 3 DIODE ARRAY
D202 4862824C03 1SV232, VARACTOR
D203 4805649Q13 1SV228, VARACTOR
D204 4805649Q13 1SV228, VARACTOR
D205 4862824C01 1SV229, VARACTOR
D301 4802245J97 DAN235ETL, DUAL
COMM CATH
D302 4802245J97 DAN235ETL, DUAL
COMM CATH
D303 4802245J97 DAN235ETL, DUAL
COMM CATH
D304 4802245J97 DAN235ETL, DUAL
COMM CATH
D305 4880142L01 MMBV3401LT, PIN
D400 4813833C07 MMBD7000, DUAL
COMM AK
D401 4813833C02 MMBD6100, DUAL
COMM CATH
D402 4809948D42 RB751V40, SCHOTTKY
D500 4813833C02 MMBD6100, DUAL
COMM CATH
D501 NOT PLACED MMBD6100, DUAL
COMM CATH
D502 4813825A23 MMSD301T1, SCHOTTKY
Circuit
Ref.
Motorola
Part No.
Description
