Motorola Radius CM200

VHF 25–45 W Band 2 PCB 8486487Z03-B / Schematics 4-23
D511 4813833C02 MMBD6100, DUAL
COMM CATH
D513 4813833C02 MMBD6100, DUAL
COMM CATH
FL300 9180022M11 MXF45, 44.85MHz BPF
FL301 9180468V06 FLTR, 455kHZ, BW
25KHZ
FL302 9180468V04 FLTR, 455kHZ, BW
12.5KHZ
FL303 9180469V03 FLTR, 455kHZ, BW
12.5KHZ
FL304 9180469V06 FLTR, 455kHZ, BW
25KHZ
J2 0989241U02 CONNECTOR 22 PIN
J3 NOT PLACED CONNECTOR 32 PIN
J11 2889309U01 ANTENNA CONNECTOR
L100 7686135U02 FERRITE BEAD
L101 2462587T30 IDCTR, 1uH
L102 2462587T30 IDCTR, 1uH
L103 2462587T30 IDCTR, 1uH
L104 2462587T38 IND CHIP 22NH 5% LOW
PRO
L105 2462587T13 IDCTR, 68nH
L106 2460591A11 IDCTR, 7.66nH
L107 2460591A01 IDCTR, 4.22nH
L108 2462587X69 IDCTR, 1.2uH
L109 NOT PLACED IDCTR, 11.03nH
L110 2462587N42 IDCTR, 12nH
L111 2460592B01 IDCTR, 51nH
L112 2460592B01 IDCTR, 51nH
L113 2460592B01 IDCTR, 51nH
L114 2460592B01 IDCTR, 51nH
L115 2460592A01 IDCTR, 17nH
L116 2460592A01 IDCTR, 17nH
Circuit
Ref.
Motorola
Part No.
Description
L117 7686135U02 FERRITE BEAD
L118 7686135U02 FERRITE BEAD
L119 7686135U02 FERRITE BEAD
L120 7686135U02 FERRITE BEAD
L121 7686135U02 FERRITE BEAD
L122 2460591C23 IDCTR, 13.85nH
L123 2462587X69 IDCTR, 1.2uH
L124 2485873L05 IDCTR, 48nH
L131 NOT PLACED IDCTR, 120nH
L132 2462587N15 IDCTR, 100nH
L200 2462587Q42 IDCTR, 390nH
L201 2462587V44 IDCTR, 680nH
L202 2462587V44 IDCTR, 680nH
L203 2462587V44 IDCTR, 680nH
L204 2462587V44 IDCTR, 680nH
L205 2462587Q47 IDCTR, 1uH
L206 2413923C05 IDCTR, 33nH
L207 2413923C07 IDCTR, 47nH
L208 2413926N24 IDCTR, 100nH
L209 2413926N24 IDCTR, 100nH
L210 2413926N24 IDCTR, 100nH
L211 2413926N24 IDCTR, 100nH
L212 2413926N24 IDCTR, 100nH
L213 2413926N24 IDCTR, 100nH
L214 2413926H20 IDCTR, 47nH
L215 2413926H20 IDCTR, 47nH
L216 2413926H20 IDCTR, 47nH
L217 2462587Q42 IDCTR, 390nH
L300 2460591G24 IDCTR, 33.47nH
L301 2462587X69 IDCTR, 1.2uH
L302 2462587X69 IDCTR, 1.2uH
Circuit
Ref.
Motorola
Part No.
Description
L303 2462587N69 IDCTR, 1.2uH
L304 2483411T74 IDCTR, 1.2uH
L305 2413926K31 IDCTR, 470nH
L306 2462587N55 IDCTR, 150nH
L307 2460591G24 IDCTR, 33.47nH
L308 2460591G24 IDCTR, 33.47nH
L309 2460591G24 IDCTR, 33.47nH
L310 2460591G24 IDCTR, 33.47nH
L311 2460591G24 IDCTR, 33.47nH
L312 2460591G24 IDCTR, 33.47nH
L313 2460591G24 IDCTR, 33.47nH
L314 2460591G24 IDCTR, 33.47nH
L315 NOT PLACED IDCTR, 27nH
L500 7686135U02 FERRITE BEAD
L501 7686135U02 FERRITE BEAD
L502 7686135U02 FERRITE BEAD
M6 4387454V01 SPACER
M9 0289511U01 NUT
M100 2680499Z01 HEATSINK
M105 7588823L03 CONTACT, METAL
M106 7588823L03 CONTACT, METAL
M107 7588823L03 CONTACT, METAL
M108 7588823L04 CONTACT, METAL
M109 7588823L04 CONTACT, METAL
M110 7588823L04 CONTACT, METAL
M111 NOT PLACED CONTACT, METAL
M112 NOT PLACED CONTACT, METAL
M113 NOT PLACED CONTACT, METAL
M114 NOT PLACED CONTACT, METAL
P1 2804503J01 CONNECTOR, 16 PIN
P2 NOT PLACED CONNECTOR, 2 PIN DC
Circuit
Ref.
Motorola
Part No.
Description
Q100 4886136B01 MRF1550, LDMOS RF
Q101 4813824A10 MMBT3904, BIPOLAR
NPN
Q102 NOT PLACED MMBT3904, BIPOLAR
NPN
Q103 4813824A06 MMBTA13, DARLING-
TON, NPN
Q105 4886212B01 MRF1518, LDMOS RF
Q106 4805128M27 BSR33, BIPOLAR, PNP
Q200 4802245J95 BFS540, NPN
Q300 4809940E02 DTC114YE, NPN
Q301 4813824A17 MMBT3906, BIPOLAR
PNP
Q302 4813824A10 MMBT3904, BIPOLAR
NPN
Q303 4802245J95 BFS540, NPN
Q304 4809939C04 UMC3
Q305 4802197J95 PBR941, NPN
Q306 4813824A17 MMBT3906, BIPOLAR
PNP
Q400 4809940E02 DTC114YE, NPN
Q401 4880141L03 BCW68G, BIPOLAR PNP
Q403 4809940E02 DTC114YE, NPN
Q404 4809940E02 DTC114YE, NPN
Q405 4809940E02 DTC114YE, NPN
Q407 4809940E02 DTC114YE, NPN
Q408 4880048M01 DTC144EKA, BIPOLAR
Q409 4880048M01 DTC144EKA, BIPOLAR
Q410 4880048M01 DTC144EKA, BIPOLAR
Q411 4880048M01 DTC144EKA, BIPOLAR
Q412 4880048M01 DTC144EKA, BIPOLAR
Q413 4809940E02 DTC114YE, NPN
Q414 4809940E02 DTC114YE, NPN
Circuit
Ref.
Motorola
Part No.
Description
