GETTING STARTED
RADIO LED INDICATORS
RADIO STATUS LED INDICATION
Channel Busy Solid Orange
Cloning Mode Double Orange Heartbeats
Cloning In Progress Solid Orange
Fatal Error at Power up
One Green Blink, One Orange Blink, One Green Blink, then repeat for 4
seconds
Low Battery Orange Heartbeat
Low Battery Shutdown Fast Orange Heartbeat
Monitor LED is OFF
Power-Up Solid Red for 2 seconds
‘Idle’ Programming Mode /
Channel Mode
Green Heartbeat
Scan Mode Fast Red Heartbeat
Transmit (Tx)/Receive (RX) Solid Red
VOX/iVOX Mode Double Red Heartbeats
