3.0 07/2009 - The data and information in this manual are subject to change at any time.
continue > adjusting the left hand closing endstop
5
- Secure the cam using the lateral
screws.
2
- Turn the cam upside down.
3
- Release the gearmotor and
completely close the gate leaf.
4
- Turn the upper cam counter-
clockwise ....
... until the switch of the micro is
released.
