L = < 1.20 m
Pag.
17
17 -
Manual code:
119R7179GB
119 R7179 G B ver.
3.0
3.0 07/2009
- The data and information in this manual are subject to change at any time.
N.B. If the gate leaf measure less than
N.B. If the gate leaf measure less than
1.2 metres ...
1.2 metres ...
... turn the upper cam upside-down and
then adjust the endstop.
5
- Secure the cam using the lateral
screws.
2
- Turn the cam upside down.
3
- Release the gearmotor and
completely close the gate leaf.
4
- turn the upper cam clockwise ....
... until the switch of the micro is
released.
1
- Remove the securing screws of
the upper cam.
ADJUSTING THE ENDSTOPS
continue > adjusts the right hand closing endstop
