3.0 07/2009 - The data and information in this manual are subject to change at any time.
1
- Assemble the pressure
hinges.
2
- Insert the hinges into the
base of the casing (either
right or left, as you prefer) and
secure them using the supplied
screws and washers.
They slide to rotate
3.1 ASSEMBLING AND SECURING THE CASING
Before securing the casing to the wall, you need to assemble and mount the hinges on the
side you prefer.
(N.B. you may also just wish to secure the cover using the 4 screws).
