Auto Clear
Angle Setup
T+A Threshold
First Peak
Bolt Audit
Spindle Audit
This feature is designed for auditing the torque applied to a fastener for a test such as determining relaxation after a
fastener has been tightened. An angle enabled transducer is required to operate in this Mode.
Bolt Audit*
Bolt Audit Thresholds
Initial Torque Threshold
450 N.m
Final Torque Threshold
650 N.m
Main
1. Press the "Menu" Button.
2. Use the Scroll Down key and select Setup by highlighting and pressing Enter.
3. Use the Scroll Up or Down key to toggle through the Setup options.
4. Press Enter key to select a setup setting for Bolt Audit.
Filter
Units
Mode
Setup
Selecting Bolt Audit
1. Press the Right or Left key to toggle between the threshold settings.
2. Use the Scroll Up or Down key to set torque thresholds.
4. Press Enter key once setting is complete.
5. Press Main button to return to main display screen.
Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 Phone: (408) 292-2214 Fax: (408) 292-2733
www.etorque.com
Page 14
Note:
* The Bolt Audit Mode is an additional feature that is only available with PTT Bolt Audit model (Item # 072995)
