Movincool Classic 40 - Control Box and Relay Board

Operation Section
23
5.2 Control Box and Relay Board
I003092
T
RS
E+
E-
L+
L-
RC
Y
G
Terminal Block
(for Signal Connection)
Terminal Block
(for Signal Connection)
Relay Board
Relay Board Fuse
Compressor Motor Relay
(for Compressor and Condenser Fan Motor)
Reverse Phase Protector
Terminal Block
(for Power Cord)
Fan Motor Relay
(for Evaporator Fan Motor)
Overcurrent Relay
(for Condenser Fan Motor)
Overcurrent Relay
(for Evaporator Fan Motor)
I003081
Relay Board Fuse (5A)
4-Position Dip Switch
“OFF” Position
CN15
CN01
CN16 CN02 CN03 CN04 CN11 CN12 CN13
CN21CN24
52CM
CN22 CN23
CN17
CN25
CN14
