2. SPECIFICATIONS
2.1 Exterior Dimension Diagram
I003082
(Unit: inch)
10.0
5.1
25.8
DIA. 13.8
DIA. 22.0
10.0
20.7
12.9
43.5
5.1
10.2
4.3
6xM6
2x6xM6
DIA. 0.6
2.8
37.8
4xM20
2.8
30.1
41.3
4.8
6.9
5.1
22.4
1.9 2.3
8.9 8.9
3.9
DIA. 20.7
11.811.8
23.6
1.6
1.6
1.2
