Moxa Technologies CP-116E-A - CP-102 E Specifications

PCI Express Boards Product Specifications
A-5
CP-102E Specifications
Hardware
Connector Male DB9 x 2
Comm. Controller 16C550C compatible
Interface
Bus Interface
PCI Express × 1
Number of Ports 2
Max No. of Boards
8
Signal
RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Performance
Baudrate 50 bps to 921.6 kbps
Configuration
Data Bits
5, 6, 7, 8
Stop Bits 1, 1.5, 2
I/O address/IRQ BIOS assigned
Parity None, Even, Odd, Space, Mark
Flow Control
RTS/CTS, XON/XOFF
Environment
Operating Temperature 0 to 55°C (32 to 132°F)
Operating Humidity 5 to 95% RH
Storage Temperature -20 to 85°C (-4 to 185°F)
ESD Protection Embedded 15 kV ESD Protection
Standards and Certifications EN55032, EN55024, EN61000-3-2, EN61000-3-3, EN61000-6-2, IEC-61000-
4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC
61000-4-8, IEC 61000-4-11,
FCC Part 15 Class B
Warranty 5 years
