PCI Express Boards Software Installation
F5 Group Edit
This convenient function allows you to edit the configuration of several ports at one time as a group.
Loading the Driver
After completing the setup procedure, run BIN\DP-DRV.EXE from the DOS prompt to load the driver. The
driver will automatically detect the boards that have already been installed. If one or more boards are
detected, you will see a message similar to the following:
Smartio/Industio Family DOS driver Version 1.7
Setup driver ...
CP-168EL series (Bus= x ,Dev=y) : OK!
Device driver setup O.K.
This indicates that the CP-168EL Series driver has been installed properly. At this point, you may execute
applications that support API-232 functions, or start developing applications using the API-232 library.
Unloading the Driver
To unload (release) the driver from memory, type DP-DRV/Q at the DOS prompt and then press Enter.
Linux (32-bit/64-bit)
Moxa provides drivers that allow you to use the following serial boards for Linux.
• PCI Express Boards: CP-118EL, CP-168EL, CP-104EL, CP-102E, CP-102EL, CP-132EL, CP-132EL-I, CP-
114EL, CP-114EL-I, CP-118E-A-I/ CP-138E-A-I/ CP-134EL-A-I/CP-116E-A
llowing procedure shows how to install the CP-114EL driver for Linux.
Execute the following commands from the Linux prompt:
1. #cd /
#mkdir moxa
#cd moxa
#cp /<driver directory>/driv_linux_smart_<version>_build_<build_date>.tgz .
#tar -zxvf driv_linux_smart_<version>_build_<build_date>.tgz
2. #cd mxser
#make clean; make install
3. #cd /moxa/mxser/driver
#./msmknod
