PoE High Power Application
PoE High Power can be enabled by DIP switch, and supply up to 36 W of
PoE power when the PSE detects an 802.3af or 802.3at connection. Refer
to the table below for the power budget at different input voltages, and
for the number of PoE High Power Ports supported.
Input Voltage
Total
Power
Budget
Number of PoE High Power Ports
12 VDC (12 to 17 VDC)
62 W
Up to 1 PoE high power port (36 W)
24 VDC (18 to 35 VDC)
120 W
Up to 3 PoE high power port (36 W)
48 VDC (36 to 57 VDC)
144 W
Up to 4 PoE high power port (36 W)
Specifications
Technology
Standards
IEEE 802.3 for 10BaseT,
IEEE 802.3u for 100BaseT(X) and 100BaseFX,
IEEE 802.3ab for 1000BaseT
IEEE 802.3z for 1000BaseX
IEEE 802.3x for Flow Control
IEEE 802.3af for PoE
IEEE 802.3at for PoE+
Processing Type
Store and Forward
Interface
RJ45 Ports
10/100/1000BaseT(X) auto negotiation speed,
F/H duplex mode, and auto MDI/MDI-X
connection
Fiber Ports
100/1000 BaseX ports (SFP Slot)
LED Indicators
Power: P1, P2
TP Port: 10/100/1000
Fiber Port: 100/1000
PoE Ports: PoE+ for Port 2, 3, 4, 5
DIP Switch
Broadcast Storm Protection, Jumbo Frame,
802.3az, Standard PoE/PoE High Power,
100/1G SFP
PoE
Total Power Budget
62 W @ 12 VDC (12 to 17 VDC)
120 W @ 24 VDC (18 to 35 VDC)
144 W @ 48 VDC (36 to 57 VDC)
PoE Output Voltage
53 VDC @ 12/24/48 VDC power input
PoE Output Power
15.4 W in 802.3af,
30 W in 802.3at,
36 W in high power mode
PoE Output Current
350 mA in 802.3af,
600 mA in 802.3at,
720 mA in high power mode
Overload Current
Protection at Port
Present
PoE Pinout
Mode A: Pair 1, 2 (V+); Pair 3, 6 (V-)

Moxa Technologies EtherDevice EDS-G205A-4POE-1GSFP-T Specifications

General

Brand	Moxa Technologies
Model	EtherDevice EDS-G205A-4POE-1GSFP-T
Category	Switch
Language	English
