Overview
The EDS-G205A-4PoE series industrial Ethernet switches are rugged
entry-level industrial 5-port Gigabit PoE switches for environments that
fall under the pollution degree 2 category. The industrial Ethernet
switches support IEEE 802.3, IEEE 802.3u, and IEEE 802.3x with
10/100/1000M, full/half-duplex, MDI/MDIX auto-sensing, and IEEE
802.3af/IEEE 802.3at PoE standards.
The EDS-G205A-4PoE series provides 12/24/48 VDC redundant power
inputs that can be connected simultaneously to a live DC power source.
The switches are available with a standard operating temperature range
from 0 to 60°C, or with a wide operating temperature range from -40 to
75°C, and their IP30 metal housing makes them rugged enough for any
harsh industrial environment.
To provide greater versatility for use with applications from different
industries, the EDS-G205A-4PoE switches also allow users to enable or
disable broadcast storm protection, 802.3az, Jumbo frame, and PoE high
power with DIP switches on the outer panel. The EDS-G205A-4PoE
switches can be easily installed on a DIN-Rail or in distribution boxes. The
DIN-Rail mounting capability and IP30 metal housing with LED indicators
make the plug-and-play EDS-G205A-4PoE switches reliable and easy to
use.
NOTE
Throughout this Hardware Installation Guide, we use EDS as an
abbreviation for Moxa EtherDevice Switch:
EDS = Moxa EtherDevice Switch
Package Checklist
Your EDS is shipped with the following items. If any of these items is
missing or damaged, please contact your customer service
representative for assistance.
• Moxa EtherDevice™ Switch
• Quick Installation Guide (printed)
• Warranty card
Features
High-watt Power-over-Ethernet
• Up to 30 watts output per PoE port (IEEE 802.3at)
• Supports PoE high power output up to 36 W
• Short circuit and over-current protection
• Auto detection for IEEE 802.3af and IEEE 802.3at
High Performance Network Switching Technology
• 10/100BaseT(X), 1000BaseT and 100/1000BaseX (SFP)
• 10/100/1000M, Full/Half-Duplex, MDI/MDIX auto-sensing
• IEEE 802.3/802.3u/802.3x
• Store and Forward switching process type, 8k MAC address entries
• 10k jumbo frames
Rugged Design
• Redundant dual 12/24/48 VDC power inputs
• Operating temperature range from 0 to 60°C, or extended operating
temperature of -40 to 75°C for (T) models.
