Moxa Technologies IESH-MB205G-C2E-R Series User Manual

- 7 -
DIN-rail Mounting
When shipped, the DIN-rail mounting kit is fixed to the back panel of
the IESH-MB. Mount the IESH-MB on the corrosion-free mounting rail
that adheres to the EN 60715 standard.
Suggested Installation Method
STEP 1:
Insert the upper lip of the DIN-
rail kit into the mounting rail.
STEP 2:
Press the device towards the
mounting rail until it snaps into
place. Alternatively, you can use
a screwdriver to attach to the
bottom of the DIN-rail kit and pull
down.
Suggested Removal Method
STEP 1:
Pull down the latch on the DIN-
rail kit with a flat-head
screwdriver.
STEP 2:
Slightly pull the device forward
and lift up to remove it from the
mounting rail.
