Moxa Technologies IMC-101 Series User Manual

- 13 -
Optical Fiber
Multi
mode
Single
mode, 40
Single
mode, 80
Distance, km
5
40
80
Wavelength, nm
1300
1310
1550
Min. TX Output, dBm
-20
-5
-5
Max. TX Output, dBm
-14
0
0
Sensitivity, dBm
-32
-34
-34
Recommended Diameter
62.5/125
9/125
9/125
(Core/Cladding) μm
(1 dB/km, 800 MHz x km)
Power Requirements
Input Voltage
24 VDC (12 to 45 VDC); redundant inputs
Input Current
0.16 A @ 24 V
Connection
Removable Terminal Block
Overload Current
Protection
1.1 A
Reverse Polarity
Protection
Present
Physical Characteristics
Casing
IP30 protection, aluminum case
Dimensions
53.6 x 135 x 105 mm
Weight
0.63 kg
Installation
DIN rail, wall mounting
Environmental Limitations
Operating
Temperature
Standard Models: 0 to 60°C (32 to 140°F),
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage
Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 90% (non-condensing)
Regulatory Approvals
Safety
UL 60950-1, UL 508, EN 60950-1
Hazardous Location
UL/cUL Class I, Division 2, Groups A, B, C and D
ATEX Class I, Zone 2, Ex nC nL IIC T4, IECEx
EMI
FCC Part 15, CISPR (EN 55022) Class A
EMS
EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 2
EN61000-4-6 (CS), Level 3
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Vibration
IEC 60068-2-6
Warranty
Warranty Period
5 years
Details
See www.moxa.com/warranty
