Moxa Technologies ioLogik E1200 Series Quick Installation Guide

- 2 -
Overview
The ioLogik E1200 series comes with 2 embedded Ethernet switch ports
that can form a daisy-chain topology, which is the easiest way to add
more Ethernet devices to a network or connect your ioLogiks in series.
Moxa’s free Active OPC Server offers active (or “push”) communication
that works between Moxa’s ioLogik units and HMI/SCADA systems,
providing instant I/O status reports by “Active Tags.” The event-driven
active tags result in an I/O response time that is faster than other OPC
Server packages.
Model Selection:
ioLogik
DI
DO
DIO
Relay
AI
AO
RTD
TC
E1210
16
-
-
-
-
-
-
-
E1211
-
16
-
-
-
-
-
-
E1212
8
-
8
-
-
-
-
-
E1213*
8
4
4
-
-
-
-
-
E1214
6
-
-
6
-
-
-
-
E1240
-
-
-
-
8
-
-
-
E1241
-
-
-
-
-
4
-
-
E1242
4
-
4
-
4
-
-
-
E1260
-
-
-
-
-
-
6
-
E1262
-
-
-
-
-
-
-
8
*The ioLogik E1213 has source DOs.
Package Checklist
• 1 ioLogik E1200 series remote I/O product
• Quick installation guide (printed)
Specifications
System
Ethernet
2 x 10/100 Mbps switch ports, RJ45
Protection
1.5 KV magnetic isolation
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, Bootp, HTTP
Power Input
24 VDC nominal, 12 to 36 VDC
Wiring
I/O cable max. 14 AWG
Dimensions
27.8 x 124 x 84 mm (1.09 x 4.88 x 3.31 in)
Weight
under 200 g
Operating Temperature
Standard Models:
-10 to 60°C (14 to 140°F)
Wide Temp. Models:
-40 to 75°C (-40 to 167°F)
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Altitude
Up to 2000 m
Note: Contact Moxa if you require products guaranteed to function
properly at higher altitudes.
Standards and
Certifications
UL 508, CE, FCC Class A
Warranty Period
5 years (excluding ioLogik E1214*)
Details
See www.moxa.com/warranty
*Because of the limited lifetime of power relay, products that use this
component are covered by a 2-year warranty.
