Moxa Technologies ioLogik E1200 Series Quick Installation Guide

- 3 -
Digital Input
Sensor Type
NPN, PNP, and Dry contact
I/O Mode
DI or Event Counter
Dry Contact
• On: short to GND
• Off: open
Wet Contact (DI to COM)
• On: 10 to 30 VDC
• Off: 0 to 3 VDC
Isolation:
3K VDC or 2K Vrms
Counter/Frequency:
250 Hz, power off storage
Digital Output (Sink)
I/O Mode
DO or Pulse Output
Pulse Wave
Width/Frequency
1 ms/500 Hz
Over-voltage Protection
45 VDC
Over-current Protection
2.6 A (4 channels @650 mA)
Over-temperature
Shutdown
175°C (typical), 150°C (min.)
Current Rating
200 mA per channel
Isolation
3K VDC or 2K Vrms
Digital Output (Source)
I/O Mode
DO or Pulse Output
I/O Type
Source
Current
0.5A per channel
Voltage
For DIO channel:
15 to 30 VDC (ext power voltage)
For DO channel:
15 to 30 VDC (ext
power voltage), 12 or 9 VDC
configurable by jumper.
Pulse Wave
Width/Frequency
1 ms/500 Hz
Over-voltage Protection
41 VDC
Over-current Limit
6 A
Over-temperature
Shutdown
175°C (typical), 150°C (min.)
Output Current Rating
1.5 A per channel
Relay Output
Type
Form A (N.O.) relay outputs, 5A
Contact Rating
5 A @ 30 VDC, 5 A @ 250 VAC, 5 A @ 110 VAC
Inductance Load
2 A
Resistance Load
5 A
Breakdown Voltage
500 VAC
Relay On/Off Time
1500 ms (max.)
Initial Insulation
Resistance
1G min. @ 500 VDC
Expected Life
100,000 times (typical)
Initial Contact Resistance
30 milli-ohms (max.)
Pulse Output
0.3 Hz at rated load
Analog Input
Type
Differential input
Resolution
16 bits
I/O Mode
Voltage / Current
Input Range
0 to 10 VDC, 4 to 20 mA
