NPort 5000 Series User Manual
104
2. The Broadcast Search window will open and display the Model, IP Address, MAC Address, and
Progress of the search for that particular device.
3. When the search is complete, the Broadcast Search window will close, and the NPort units that were
located will be displayed in the right panel of the Administrator window. If you found more than one
server connected to this network, refer to the MAC address sticker on your server(s) to determine which
server(s) are the ones you wish to configure. To configure an NPort, place the cursor over the row
displaying that NPort’s information, and then double click the left mouse button.
ATTENTION
Before modifying the NPort’s configuration, use Broadcast Search to locate all NPort units connected to the
LAN, or use Specify by IP Address to locate a particular NPort.
Unlock Password Protection
The NPort device server is password protected (the default username is admin, password is moxa). The
status of the NPort device will be indicated by Lock. You will receive the following error, and you will not be
able to right-click to open the configuration page.

Moxa Technologies NPort 5230 Specifications

General

Isolation	1.5 kV
Certification	CE, FCC, EN
Serial interface type	RS-232, RS-422, RS-485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Surge protection voltage	0.5 kV
Ethernet LAN (RJ-45) ports	1
Supported network protocols	ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, HTTP, SMTP, IGMP v1/2
Compatible operating systems	Windows 95/98/ME/NT/2000/XP/2003/Vista Windows XP/2003/Vista (32/64-bit) SCO Unix SCO OpenServer UnixWare 7 UnixWare 2.1, Unix SVR 4.2 Unix QNX 4.25, QNX 6 Solaris 10 FreeBSD AIX 5.x HP-UX 11i
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	12 - 48 V
Safety	UL, TÜV, DNV

Weight and Dimensions

Weight	340 g
Dimensions (WxDxH)	67 x 100.4 x 22 mm
