NPort 5000 Series User Manual
9
Connecting to the Network
Connect one end of the Ethernet cable to the NPort’s 10/100M Ethernet port and the other end of the cable
to the Ethernet network. The NPort device server will indicate a valid connection to the Ethernet in the
following ways:
• The Ethernet LED maintains a solid green color when connected to a 100 Mbps Ethernet network.
• The Ethernet LED maintains a solid orange color when connected to a 10 Mbps Ethernet network.
• The Ethernet LED will flash when Ethernet packets are being transmitted or received.
ATTENTION
NPort IA5000/IA5000A/5600-8-DT series NPorts have two Ethernet ports that can be used to create an
open chain of NPort IA5000/IA5000A/5600-8-DT device servers. Be careful not to connect the Ethernet
ports of the two device servers at the ends of the chain.
In other words, NPort IA5000/IA5000A/5600-8-DT series NPorts do NOT support closed chains.
Connecting to a Serial Device
Connect a serial data cable between the NPort and the serial device. Serial data cables must be purchased
separately. They are not provided with the NPort.
LED Indicators
NPort 5100/5100A/P5150A Series
LED Name
LED Color
LED Function
Ready
Red
Steady on:
Power is on, and the NPort is booting up.
Blinking:
Indicates an IP conflict, or the DHCP or BOOTP server did not
respond properly.
Green
Steady on:
Power is on, and the NPort is functioning normally.
Blinking:
The device server has been located by NPort Administrator’s
Location function.
Off
Power is off, or a power error condition exists.
Link
Orange
The device is connected to a 10 Mbps Ethernet connection.
Green
The device is connected to a 100 Mbps Ethernet connection.
Off
The Ethernet cable is disconnected, or has a short.
Tx/Rx
Orange
The serial port is receiving data.
Green
The serial port is transmitting data.
Off
Data is NOT being transmitted or received through the serial port.
NPort 5200/5200A/5400 Series
LED Name
LED Color
LED Function
Ready
Red
Steady on:
Power is on, and the NPort is booting up.
Blinking:
Indicates an IP conflict, or the DHCP or BOOTP server did not
respond properly.
Green
Steady on:
Power is on, and the NPort is functioning normally.
Blinking:
The device server has been located by NPort Administrator’s
Location function.
Off
Power is off, or a power error condition exists.
Link
(Ethernet)
Orange
The device is connected to a 10 Mbps Ethernet connection.
Green
The device is connected to a 100 Mbps Ethernet connection.
Off
The Ethernet cable is disconnected, or has a short.
P1, P2,
(P3, P4)
Orange
The serial port is receiving data.
Green
The serial port is transmitting data.
Off
Data is NOT being transmitted or received through the serial port.

Moxa Technologies NPort 5230 Specifications

General

Isolation	1.5 kV
Certification	CE, FCC, EN
Serial interface type	RS-232, RS-422, RS-485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Surge protection voltage	0.5 kV
Ethernet LAN (RJ-45) ports	1
Supported network protocols	ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, HTTP, SMTP, IGMP v1/2
Compatible operating systems	Windows 95/98/ME/NT/2000/XP/2003/Vista Windows XP/2003/Vista (32/64-bit) SCO Unix SCO OpenServer UnixWare 7 UnixWare 2.1, Unix SVR 4.2 Unix QNX 4.25, QNX 6 Solaris 10 FreeBSD AIX 5.x HP-UX 11i
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	12 - 48 V
Safety	UL, TÜV, DNV

Weight and Dimensions

Weight	340 g
Dimensions (WxDxH)	67 x 100.4 x 22 mm
