- 7 -
Blinking
The corresponding module port’s
data is being transmitted at
1000 Mbps.
On
The corresponding module port’s
data is being transmitted in full
duplex mode.
FDX/HDX GREEN
Off
The corresponding module port’s
data is being transmitted in half
duplex mode.
On
The corresponding module’s port is
the ring or chain port of this PT
switch.
RING/CHAIN
PORT
GREEN
Off
The corresponding module’s port is
not the ring or chain port of this PT
switch.
On
The corresponding module’s port is
the coupler port of this PT switch.
COUPLER
PORT
GREEN
Off
The corresponding module’s port is
not the coupler port of this PT
switch.
Specifications
Technology
Standards IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D,
802.1w, 802.1Q, 802.1p, 802.1X, 802.3ad
Flow control IEEE 802.3x flow control, back pressure flow control
Interface
Fast Ethernet 10/100BaseT(X) or 100BaseFX (SC/ST connector or
SFP slot)
Gigabit Ethernet 10/100/1000BaseT(X), 1000BaseSX/LX/LHX/ZX
(SFP slot, LC connector)
System LED
Indicators
STAT, PWR1, PWR2, FAULT, MSTR/HEAD,
CPLR/TAIL
Module LED
Indicators
LNK/ACT, FDX/HDX, SPEED, RING
/CHAIN
PORT, COUPLER PORT
Alarm Contact One relay output with current carrying capacity of 3A
@ 30 VDC or 3A @ 240 VAC
Optical Fiber (100BaseFX)
Distance Multi-mode
0 to 5 km, 1300 nm (50/125μm, 800 MHz*km)
0 to 4 km, 1300 nm (62.5/125μm, 500 MHz*km)
Single-mode
0 to 40 km, 1310 nm (9/125μm, 3.5 PS/(nm*km))
0 to 80 km, 1550 nm (9/125um, 19 PS/(nm*km))
Min. TX Output Multi-mode: -20 dBm; Single-mode: -5 dbm
Single-mode 80 km: -5 dBm
Max. TX Output Multi-mode: -10 dBm; Single-mode: 0 dbm
Single-mode 80 km: 0 dBm
RX Sensitivity Multi-mode: -32 dBm; Single-mode: -34 dbm
Single-mode 80 km: -34 dBm
Power
Input Voltage 24 VDC (18 to 36V)or 48 VDC (36 to 72V)or 110/220
VDC/VAC
(88 to 300 VDC and 85 to 264 VAC)
Input Current Max. 2.58A @ 24VDC
