- 8 -
Max. 1.21A @ 48VDC
Max. 0.64/0.33A @ 110/220VDC
Max. 0.53/0.28A @ 110/220VAC
Physical Characteristics
Housing IP 30 protection, metal case
Dimensions
(W x H x D)
440 x 44 x 325 mm (17.32 x 1.73 x 12.76 in.)
Weight 5900 g
Installation 19” rack mounting
Regulatory Approvals
Safety UL60950-1, CSA C22.2 No. 60950-1, EN60950-1
Power Automaton IEC61850-3, IEEE 1613
Road Traffic NEMA TS2
Rail Traffic EN50121-4, EN50155
EMI FCC Part 15, CISPR (EN55022) class A
Environmental Limits
Operating Temp. -40 to 85°C (-40 to 185°F)
Cold start of min. 100 VAC at -40°C
Storage Temp. -40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity.
5 to 95% (non-condensing)
Warranty
5 years
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll-free: 1-888-669-2872
Tel: +1-714-528-6777
Fax: +1-714-528-6778
Moxa China (Shanghai office):
Toll-free: 800-820-5036
Tel: +86-21-5258-9955
Fax: +86-10-6872-3958
Moxa Europe:
Tel: +49-89-3 70 03 99-0
Fax: +49-89-3 70 03 99-99
Moxa Asia-Pacific:
Tel: +886-2-8919-1230
Fax: +886-2-8919-1231
