Moxa Technologies UPORT 1130 User Manual

UPort 1100 Series Installation and Configuration
2-16
Install Linux Driver
Linux Kernel 2.4.20 and above
The Linux driver for the Moxa UPort 1000 Series converters will map Linux host ttyUSBxx ports to UPort device
ports. Once the mapping has been set up, Linux users and applications can connect to a device port as if it were
a ttyUSBxx port. These drivers have been designed and tested for the majority of Linux distributions, including
Linux kernel version 2.4.20 and above. Please check Moxa’s website (http://www.moxa.com) for the latest
Linux kernel support.
The Linux drivers support the following models:
• UPort 1110: 1-port RS-232 USB-to-Serial Converter.
• UPort 1130: 1-port RS-422/485 USB-to-Serial Converter.
• UPort 1130I: 1-port RS-422/485 USB-to-serial converter with isolation protection.
• UPort 1150: 1-port RS-232/422/485 USB-to-Serial Converter.
• UPort 1150I: 1-port RS-232/422/485 USB-to-Serial Converter with isolation protection.
In this section, we provide four procedures to introduce the Moxa Linux Driver.
1. Installing the Linux Driver File
2. Loading/Unloading the Moxa Driver
3. Setting the Serial Parameters
4. Remover the Moxa Linux Driver
Installing the Linux Driver Files
Obtain the driver file from the Document and Software CD, or from the Moxa website at
http://www.moxa.com
.
To install and load the Linux drivers, enter the following commands from the Linux prompt:
# mount /dev/cdrom/ mnt
# cd /
# mkdir moxa
# cd /moxa
# cp /mnt/<driver directory>/driv_linux2.4_uport1p_vx.x_build_yymmddhh.tgz/moxa
# tar -xvfz driv_linux2.4_uport1p_vx.x_build_yymmddhh.tgz
# cd /mxu1100_24/driver
# make clean
# make install
*Note: yy = year, mm = month, dd = day, hh = hour
Loading the Moxa Driver
After installing the driver you can load the Moxa driver. The driver will be loaded automatically when the UPort
1100 is plugged into your PC, or you can load the driver manually.
# modprobe mxuport1100_24
You can verify that the driver has loaded by entering the following command:
# lsmod
For additional information, please refer to readme.txt in the mxuport1100_24 directory.

Moxa Technologies UPORT 1130 Specifications

General

Connector 1	USB
Connector 2	DB-9M
Connector 1 gender	Male
Depth (imperial)	2.36 \
Width (imperial)	1.51 \
Height (imperial)	0.79 \
Weight (imperial)	0.14 lbs
Dimensions (WxDxH)	38.4 x 60 x 20 mm
Product color	Silver
Data transfer rate	0.012 Gbit/s
Compatible operating systems	Windows 98, ME, 2000, XP (x86/x64), 2003 (x86/x64), Vista (x86/x64) WinCE 5.0 Linux 2.6 (x86/x64), Linux 2.4 (x86/x64)
Input voltage	5 V

Weight and Dimensions

Weight	65 g
