8
Air 2S Installation
Attaching the Tripod
2 screw holes are equipped at the bottom of grip: 1/4” for mini tripod and 3/8” for large
accessories like slider and big tripod. Screw the mini tripod, then expand as shown
below.
Battery startup and shutdown
a. Long press the power button
b. Press the power button of battery, then long press the power
button again three seconds later. After the battery indicator lights
turn off from left to right, release the battery on key and the
battery will turn off.
c. When the battery is in the off state of PTZ, it will automatically
turn off 10 minutes later. To start the PTZ, you need to turn on the
battery first.
It is recommended to press the on / off key of the stabilizer for a long time
to turn off the stabilizer, and then turn off the battery according to the
operation when shutting down.
