6 Fault elimination
Maschinenfabrik Reinhausen GmbH 202048 5788897/03 ENVACUTAP
®
VVS
®
14. Remove one of the 4 brackets on the energy accumulator and secure it
at the top of the selector switch insert. The bracket must face inwards.
The bracket fitted in this way has a maximum load-bearing capacity of 60
kg. Only use the bracket to pull the selector switch insert out.
Figure30: Securing the bracket
15. Align the selector switch insert centrally such that the upper contact fin-
gers release from the neutral point ring .
Figure31: Aligning the selector switch insert
