MrCool Universal Series - Dimensions

mrcool.com23
UNIT INSTALLATION
3
3.5 Dimensions
MDPH180244 / MDPH180364 / MDPH180484 / MDPH180604
Model A B C D
MDPH180244
MDPH180364
49-1/4 (1250) 44 (1120) 35-7/16 (900) 2-1/2 (65)
Side Air Vents
E
Size of Air Return
G I
Size of Air Supply
K
F H J L
4-7/16
(113)
17-8/16
(445)
16-9/6
(420)
3-7/16
(87)
3-15/16
(101)
15-6/16
(390)
11-13/16
(300)
6-3/16
(157)
Bottom Air Vents
M
Size of Air Return
O R
Size of Air Supply
S
N P Q T
5-4/16
(149)
23-1/16
(586)
8-10/16
(219)
3-11/16
(93)
6-3/16
(156)
11-14/16
(302)
13-12/16
(350)
3-10/16
(92)
Unit: inch (mm)
