MrCool Universal Series Service Manual

mrcool.com3
PRODUCT OVERVIEW
1
1.3 Features
Feature Description
DC Inverter Technology
The unit is equipped with an ecient DC compressor and fan motor which can
adjust output capacity and reduce power consumption.
Non-Polarity
Communication Design
Directly connected to the wired controller with a two-core unshielded cable up to
328 feet (100 meters).
Anti-Corrosive & Dust-
proof Design
Both the indoor and outdoor units feature anti-corrosive coating, triple-layer
moisture-proof paint, an IP56 standard outdoor fan motor, and a hermetically
sealed indoor fan motor, which greatly improve the system's durability.
Multi-Protection Design
Built-in comprehensive protection includes high/low pressure protection, over-
current protection, high-discharge temperature
Multi-Parameter
Throttling Control Design
The operation process is substantially optimized by an electronic expansion valve
that manages high and low pressure, and compressor discharge temperature.
Dead Wind Start-Up
Design
The outdoor fan's dead wind start-up function greatly improves the success rates
of fan startup during windy conditions and ensures a steady performance.
Emergency Operation
Design
The unit is composed of two dierent systems. When one system fails, the other
will continue to operate in an emergency status.
Centralized Control One centralized controller can control up to 36 hosts.
Remote Control Function
Remote control can access host through LAN and WAN. (Gateway access is
required.)
Model MDPH180244 MDPH180364
Capacity
Cooling
kW 7.03 10.08
BTU/h 24000 34400
Heating
kW 7.03 10.55
BTU/h 24000 36000
SEER - 17.8 17.8
HSPF - 8.8 8.8
EER (Btu/h)/W 11 11
COP W/W 3.4 3.4
Power Supply V/Ph/Hz 208/230/160 208/230/160
MOP A 40 40
MCA A 35 35
Refrigerant Charge Volume lbs 11 11
Sound Pressure Volume dB(A) 63 63
Dimension
(WxDxH)
Outline in 44-1/8 x 35-3/8 x 49-3/16 44-1/8 x 35-3/8 x 49-3/16
Package in 44-5/8 x 35-15/16 x 50-13/16 44-5/8 x 35-15/16 x 50-13/16
Net Weight/Gross Weight lbs 523/545 523/545
Loading
Quantity
40'GP/40'HQ unit 26/52 26/52
1.4 Product Data

MrCool Universal Series Specifications

General

Type	Inverter
Brand	MrCool
Series	Universal Series
Refrigerant	R410A
Phase	1
Heating Capacity	Varies by model
Cooling Capacity	Varies by model
Compatibility	Universal
HSPF Rating	10
Voltage	208/230V
Operating Temperature (Cooling)	Varies by model
Operating Temperature (Heating)	Varies by model
Indoor Noise Level (dB)	Varies by model
Outdoor Noise Level (dB)	Varies by model
Indoor Unit Dimensions (H x W x D)	Varies by model
Outdoor Unit Dimensions (H x W x D)	Varies by model
Indoor Unit Weight	Varies by model
Warranty	5 years
