No. Display Description
21 E-Heater On/O Switch of auxiliary heating
22 Memory
Memory Status (After power failure and re-energizing the unit, it will resume to ON/OFF status of
unit before the power failure.)
23 Clean Filter washing reminder
24 Save Display when energy-saving function is set
25 Defrost Defrosting status
26 Timer Display when timer status is set
27 Shield Shielding status
2.2 Buttons
No. Description Functions
1 Swing/Enter
Function selection & canceling; Press for 5s to view ambient temperature; press Mode button
to view outdoor ambient temperature or indoor ambient temperature
2 Timer Timer setting
3 (Up Arrow)
Running temperature range of indoor unit: 60.8-86°F (16-30°C);
Timer Setting Range: 0.5-24hrs
Setting of air function level; Setting of energy-saving temperature; Setting of cleaning class
7 (Down Arrow)
4 Mode Setting of auto/cooling/heating/fan/dry mode of indoor unit
5 Function Switch between swing/air/sleep/health/I-Demand/out/turbo/save/e-heater/X-Fan/clean/quiet
6 Fan Setting of high/medium, high/medium/medium, low/low/auto fan speed
8 On/O Turn on/o indoor unit
4 & 3
Memory
Function
Press mode and arrow up buttons at the same time for 5s when unit is o to access the
memory function. (If memory function is set, the indoor unit will resume its original setting
state after power failure and power recovery. If not, he indoor unit will default to an o status
after power recovery. Ex-factory setting of memory function is on).
3 & 7 Lock
Upon startup of the unit without malfunction or under o state of the unit, press the up
and down buttons at the same time for 5 seconds to enter lock state. In this case, any other
button will not respond when pressed. Press the up and down arrow buttons again for 5
seconds to quit lock state.
4 & 5
Inquiry and
Setting of Wired
Controller
While the unit is powered o, press the Mode and Function buttons at the same time for 5
seconds to set the address.
WIRED CONTROLLER
